Specifications
Round Dripper Mold.THE MOLD MATERIAL IS SWEDEN STEEL.
Certificate:ISO9001.
Round Dripper Mold .
ONE: MOLD PARAMETER
Cavity quantity |
Sixteen cavities |
Thirty-two cavities |
note |
|
Overall dimension of the mold(mm) |
270×400×250 |
450×600×350 |
|
Flow path mode |
Cold runner mold/hot runner mold |
Hot runner mold |
|
Gate forms |
Submarine gate |
Submarine gate |
Balance material feeding, automatically interrupted pouring |
Pushing-out mode |
Once pushing-out of ejector pin |
Once pushing-out of ejector pin |
Making sure that final product will drop off automatically |
Cooling mode |
Water-cycle cooling |
Water-cycle cooling |
|
Working mode |
Automatic production |
Automatic production |
|
Service life |
One million |
One million |
|
Producing deviation |
≤5% |
≤5% |
Deviation of emitter flowing rate |
Emitter specifications |
|
|
|
Mode of injection molding machine for it |
ZF1600-A |
ZF2400-A |
|
TWO:THE ROUND DRIPPER PRODUCED BY THE MOLD
THREE:THE DESCREPTION OF THE MOLD :
Themachine brand to produce mold is Switzerland ARGE CHARMILES and the mold material is Sweden steel. The mold has high accuracy with the treatment of nitriding and tempering, making the proceed mold precision very high and reach the European standard.
