Specifications
BMD-T9041000 Mobile Light Tower with diesel generator(outdoor lamp)7meters,
4*1000W metal halide lamps, 10KW diesel gensets
BMD-T9041000 Mobile Light Tower with diesel generator(outdoor lamp)
The max height of light mast |
Power |
|
BMD-T704500 |
7,000mm |
4×500W |
BMD-T904500 |
9,000mm |
4×500W |
BMD-T9041000 |
9,000mm |
4×1000W |
The height of light mast can be made according to customers requirement.
Model BMD-T9041000 Mobile Light Tower, an integrated portable lighting, consists of generator, generator chassis, pneumatic mast, 4 dual crystal dysprosium lamps with each 1,000W, control box and so on.
Technical Parameters
Specification name |
Unit |
value |
|
Rated voltage |
V |
AC220 |
|
power |
W |
4×1000 |
|
Supply voltage |
V |
AC220 |
|
Luminous flux |
Lm |
88,000 |
|
Average service life |
h |
8,000 |
|
Continuous working time |
Alternating current |
|
Long-time working |
Fill fuel fully |
h |
13 |
|
Minimum height of telescopic cylinder |
mm |
1,800/2,000 |
|
Maximum height of telescopic cylinder |
mm |
7,000/9,000 |
|
Gasoline generator |
Rated output voltage |
AC220/50Hz |
|
Rated output/rated volume of fuel tank |
8.5KAV/15Lit |
||
Start-up type |
Manual |
||
model |
4 stroke, air cooled |
||
Dimension (size) |
length×width×height |
1750×500×800 |
|
weight |
Total |
198 |
|
