Specifications
compression spring testing machine1.Digital display
2.Spring tensile,compression testing
3.CE certificate
TLS Series Tension & Compression Spring Testing Machine
Application:
Itis based on the country's spring and compressive tester standards of technical requirement is made, professional design of automatic control and data acquisition system, realized the data acquisition and control process full digital adjustment. Can the compression spring, dish above precision extension spring, spring, spring, leaf-spring tower, card of spring, spring, spring, composite, gas springs, die spring, and special springprecision tension of the spring, stress, displacement, stiffness and strength test and analysis.
Main specification:
Model |
TLS |
Max testng force |
10KN,20KN,50 KN |
Testing force range |
2%-100% |
accuracy |
±1% |
Displacement resolution |
0.01mm |
Displacement mesure accuracy |
± 1% |
Tesnsile space |
700mm or more |
Compression space |
700mm or more |
Testing space |
700mm |
Add load speed |
0.05mm~500mm |
Displacement speed control accuracy |
± 1% |
Tester level |
1 calss |
Deformation indicating error |
≤±( 50+0.15L) |
Power supply |
220V/50HZ |
Tension & Compression Spring Testing Machine
CE Certificate:
