HST650 Ultrasonic Flaw Detector

HST650 Ultrasonic Flaw Detector thumbnail-1
HST650 Ultrasonic Flaw Detector photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
HST
Model Number:
MUT650
Contact Supplier Request Quote Chat Now
Jinan Hensgrand Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name HST
Model Number MUT650

Specifications

Ultrasonic Flaw Detector
1. Automated calibration
2. Digital display

Digital Ultrasonic Flaw Detector


♦ Automated calibration,Automated gain

 ♦   DAC,AVG,TCG,B scan,AWS

 ♦   High-speed capture and very low noise

 ♦  high contrast viewing of the waveform from bright

 ♦   Powerful pc software and reports can be export to excel



Features

  • Automated display precise flaw location(Depth d,level p,distance s,amplitude,sz dB,Φ);
  • Automated switch three staff gauge ((Depth d,level  p,distance s);
  • Automated calibration of transducer Zero-point, Angles, Front edge and material Velocity ;
  • Convenient to make and use DACTCG and AVG to evaluate the echo, the curve can be modified and compensated
  • 6dB DAC functions;
  • Standards of test for DAC is saved.
  • 500 independence setup, any criterion can be input freely, we can work in the scene without test block;
  • Big memory of 1000 A graph
  • Automated gain and gain scan;
  • Peak Hold and Peak Memory;
  • B scan;
  • AWS D1.1
  • Automated make video of test process and play; use upan,the length of video is unlimited.
  • Powerful pc software and reports can be export to excel;
  • Li battery, continue working time up to 10 hours;
  • The embeded software can be online updated;



Other assistant function

  • Display freeze;
  • Automated echo degree;
  • Angles and K-value;
  • Lock and unlock function of system parameters;
  • Electronic clock calendar ;
  • Two gates setting and alarm indication;
  • Gate and DAC alarm;



Specifications



Title

Parameter

Title

Parameter

Measuring Range(mm)

0 ~  10000

Measurement Mode

Single,Dual,Thru

Vertical Linearity Error

≤3%

Reject

0~80%

Horizontal Linearity Error

≤0.1%

Pulse Displacement(μs)

-20 ~  +3400

Sensitivity Leavings

≥62dB

Zero(μs)

0.0 ~  99.99

Dynamic range

≥34dB

Port Type

BNC(Q9)

Resolving Power

≥36dB

Operating Temperature  (°C)

-20~50

Frequency Range(MHz)

0.5 ~  20

HxWxD(mm)

240x156x50

Gain(dB)

0 ~  120

Weight(kg)

1.0(with battery)

Material Velocity(m/s)

1000 ~  15000









HST650 Ultrasonic Flaw Detector



MUT650 Automated calibration Digital Ultrasonic Flaw Detector



HST650 Ultrasonic Flaw DetectorHST650 Ultrasonic Flaw DetectorHST650 Ultrasonic Flaw Detector





MUT650 Automated calibration Digital Ultrasonic Flaw Detector





HST650 Ultrasonic Flaw Detector
