charpy impact test use low temperature humidity chamber
Low temperature test chamber is designed according to charpy notch impact test method for metal materials, and adopts compressor cooling technology. It utilizes the heat balance principle and cycle stirring method to realize the constant temperature cooling to impact specimen with the reliable performance. Digital display, automatic control temperature, and it is the ideal equipment for cooling and keeping temperature to impact specimen.
Standards:
ASTM, E23-02a, En10045, ISO83,GB/T229-2009,CE
Low temperature chamber specifications:
Model |
DWC-40 |
DWC-60 |
DWC-80 |
DWC-100 |
|||
|
Temperature range
|
+30~-40°C |
+30~-60°C |
+30~-80°C |
+30~-100°C |
|||
|
Temperature Control Accuracy |
±0.5°C |
||||||
|
Temperature dropping speed
|
+30°C~0°C 1.2°C/min |
+30°C~0°C 2°C/min |
+30°C~0°C 2°C/min |
+30°C~0°C 2°C/min |
|||
|
0°c~-20°C 0.8°C/min |
0°c~-20°C 1.5°C/min |
0°c~-20°C 1.5°C/min |
0°c~-20°C 1.5°C/min |
||||
|
-20°C~-40°C 0.5°C/min |
-20°C~-40°C 1.0°C/min |
-20°C~-60°C 1.0°C/min |
-20°C~-40°C 1.0°C/min |
||||
|
-40°C~-60°C 0.7°C/min |
-60°C~-80°C 0.7°C/min |
-60°C~-100°C 0.7°C/min |
|||||
|
Cold Room Volume |
150*505*240mm |
||||||
Dimensions |
900*505*850mm |
900*505*850mm |
900*505*850mm |
1500*1200*1200mm |
|||
|
Box Material
|
Steel Spray |
||||||
|
Loading the number of samples |
>60 |
>60 |
>60 |
>200 |
|||
|
Mode of refrigeration
|
Compressor refrigeration |
||||||
|
Cooling Medium
|
Ethanol or other unfrozen liquid |
||||||
|
Power
|
7Kw |
7Kw |
7Kw |
7Kw |
|||
Features:
1. Imported compressor, DANFUS valve, imported evaporation-condensation machine;
2. Controlled by intellligent instrument, digital presentation temperature value, automatic control temperature, automatic time and alarm.
3. High security, refrigerate fast, large volume
HST low temperature chamber --- help cooling impact samples like metal
Imapct test steps:
CE certificate :
Our low temperature chamber can be delivery within 3 working days after receiving payment, the products can be shipped by air, by sea or by express delivery !
Dear customer, if you need our temperature chamber or other testing machines, please do not hesitate to contact us ! We will supply our best service for you ! Best Wishes !
