Home > Products > Hydraulic Universal Testing Machine > WAW 200 Tons 2000kn Universal Tensile Testing Machines
WAW 200 Tons 2000kn Universal Tensile Testing Machines
- Qingdao or other port as your request
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
WE-300D 300KN Digital Display Hydraulic Universal Test Machine Price
-
WEW 300KN 30TON Hydraulic Univeral Testing Machine Price
-
China Factory WEW-D 300KN 600KN 1000KN Hydraulic Universal Compression Tension Testing Machine
-
Cement Mortar Hydraulic Compression Testing Machine
-
Hydraulic Motors Dynamic Balance Testing Machines
-
Hydraulic Tension Strength Testing Machine 100ton
Product Details
| Place of Origin | Shandong, China | Brand Name | HST | |
| Model Number | WAW-2000H | Power | Hydraulic | |
| Usage | Universal Testing Machine |
Product Description
WAW 200 Tons 2000kn universal tensile testing machines
Contact Sunny: Whatsapp/line+86-15589960023 Skype: jessica-hssd
1.Application:
The machine adopts Hydraulic Loading, Computer Control, easy and convenient to operate.
It is mainly used to execute the tension, compression, bending, shearing, flexural etc. test for metal
materials. Attached with simple accessories and devices, it can be used to test wood, concrete,
cement, rubber, and so on.
It is very suitable for making test to different metal or nonmetal materials under high toughness and
hardness against extreme big loading force.
2.Main Specifications:
Model | WAW-2000H |
Structure | 6 Column (Four Columns Two Ball Screws) |
Control Way | Constant Stress Uniform Deformation Constant Displacement Three Closed Loop Control And Program Control |
Max.Load | 2000 KN (200 TONS) |
Load Accuracy | ≤±1% (Optional: ≤± 0.5%) |
Load Range | 2%~100%FS (40KN~2000KN) (Optional: 0.4%-100%FS (8KN~2000KN)) |
Load Resolution | 1/300000 |
Deformation Measurement Range | 2%~100%FS |
Deformation Accuracy | ≤±1% (Optional: ≤± 0.5%) |
Displacement Resolution | 0.01mm |
Displacement Error | ≤±0.5% |
Max. Piston Stroke | 250mm |
Max. Piston Moving Speed | 0-50mm/min Stepless Speed Adjusting |
Crossbeams Lifting Speed | 200mm/min |
Max. Tension Test Space | 1000mm (Can Be Customized) |
Max. Compression Test Space | 750mm (Can Be Customized) |
Center Spacing Between Columns | 910mm |
Column Effective Spacing | 780mm |
Clamping Method | Hydraulic Automatic Clamp |
Round Specimen Clamping Range | Φ12-Φ30mm, Φ30-Φ50mm, Φ50-Φ70mm |
Flat Specimen Clamping Range | 0-35mm (Optional: 35-70mm) |
Flat Specimen Clamping Width | 115mm |
Flat Specimen Clamping Length | 160mm |
Compression Plate Size | Φ160mm |
Bending Roller Distance | 450mm |
Width Of Bending Rollers | 120mm |
Intensify Equipment Form | Built Intensify |
Crossbeam Lifting Method | Nut Rotating |
Mechanical Strength | Strength Of 3.5 Times |
Power Supply | 3-phase, AC380V, 50Hz (Can Be Customized) |
Host Weight | 8100.00 KG |
Host Size (L*W*H) | 1620*1050*3370mm |
Hydraulic testing machine
WAW 200 Tons 2000kn universal tensile testing machines
Our advantages with others brand:
One year guarantee of the whole machine
24 hours techonical support by e-mail
calling or door-to-door service
WAW 200 Tons 2000kn universal tensile testing machines
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 20 years focusing on test instruments field,6 years exporting experience.
Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 16 months by HST,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest
problems and complaints in a professional and timely.
Q:What about the product' services and quality?
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need.
products are widely recognized and trusted by users.
