Product Details
| Place of Origin | Shandong, China | Brand Name | Hensgrand | |
| Model Number | WAW-2000D | Power | Electronic | |
| Usage | Universal Testing Machine |
Product Description
high precision servo motor electro-hydraulic testing machine 2000KN
The machine adopts hydraulic loading, digital display, easy and convenient to operate. It is mainly used to execute the tension, compression, bending, shearing etc. Mainly test for metal materials.
Attached with simple accessories and devices, it can be used to test wood, concrete, cement, rubber and so on. It is very suitable for making test to different metal or nonmetal materials under high toughness and hardness against extreme big loading force.
High quality computer display hydraulic universal testing machine:
Good price for computer display hydraulic universal Testing machine specification :
Model | WAW-100D | WAW-300D | WAW-600D | WAW-1000D | WAW-2000D | ||||||||
Control mode | Constant Stress, Deformation, three Closed Loop Control | ||||||||||||
Max. Load | 100KN | 300KN | 600KN | 1000KN | 2000KN | ||||||||
Tension test space | 650mm | 750mm | |||||||||||
Compression Test Space | 500mm | 600mm | |||||||||||
Round specimen clamping diameter (mm) | Φ4-Φ21 | Φ10-Φ32 | Φ13-Φ40 | Φ13-Φ50 | Φ15-Φ70 | ||||||||
Flat specimen clamping thickness (mm) | 0-15mm | 0-30mm | 0-60mm | ||||||||||
Flat specimen clamping width | 70mm | 75mm | 85mm | ||||||||||
Compression plate size | φ160mm/φ240mm | Φ240mm | |||||||||||
Bending roller distance | 450mm | ||||||||||||
Width of bending rollers | 120mm | 160mm | |||||||||||
Load accuracy | ≤±1% or ≤± 0.5% | ||||||||||||
Load range | 2%-100%of Full Scale or 0.4%-100% of Full Scale | ||||||||||||
Load resolution | 1/300000 of Full Scale | ||||||||||||
Deformation Measurement Range | 2%~100% of Full Scale | ||||||||||||
Deformation accuracy | ≤±1% or ± 0.5% | ||||||||||||
Displacement resolution
| 0.01mm | ||||||||||||
Displacement accuracy | ≤±0.5% | ||||||||||||
Piston stroke | 250mm | ||||||||||||
Lifting speed of mobile beams | 150mm/min | ||||||||||||
Clamping method | Hydraulic automatic clamping | ||||||||||||
Power supply | 3-phase, AC380V, 50Hz(can be customized) | ||||||||||||
Different color but same theory for computer display hydraulic universal testing machine every parts name picture:
Computer with windows system, can let machine make compression or tension testing automatic ! Easy to operate !
With below texting machine, there has printing machine, can print out testing result directly !
Hydraulic universal testing machine can load 100KN, 300KN, 600KN, 1000KN metal and non-metal materials.
At below is testing software use on computer :
Different jigs for different materials testing use :

Customers come to visit our factory, check testing machine quality ! Good quality indeed !
Testing machines in stock :
This is our company photo:
CE certificate:
First one CE certificate is for our Electronic Universal Testing Machines :
At below CE certificate is for our Hydraulic Universal Testing Machines :
Our testing machines can be delivery within 5 working days --15 working days after receiving payment, the products can be shipped by air, by sea or by express delivery !
1) Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 20 years focusing on test instruments field,6 years exporting experience.
2) Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
3) Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 16 months by HST,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest
problems and complaints in a professional and timely.
4) Q:What about the product' services and quality?
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need. Products are widely recognized and trusted by users.
