Home > Instruments & Meters > Test Instrument > Test Machine > WDW-G Computerized Electronic Rupture Creep Testing Machine

WDW-G Computerized Electronic Rupture Creep Testing Machine

WDW-G Computerized Electronic Rupture Creep Testing Machine thumbnail-3

WDW-G Computerized Electronic Rupture Creep Testing Machine thumbnail-4

WDW-G Computerized Electronic Rupture Creep Testing Machine thumbnail-5

WDW-G Computerized Electronic Rupture Creep Testing Machine thumbnail-6

WDW-G Computerized Electronic Rupture Creep Testing Machine photo-1

WDW-G Computerized Electronic Rupture Creep Testing Machine photo-2

WDW-G Computerized Electronic Rupture Creep Testing Machine photo-3

WDW-G Computerized Electronic Rupture Creep Testing Machine photo-4

WDW-G Computerized Electronic Rupture Creep Testing Machine photo-5

WDW-G Computerized Electronic Rupture Creep Testing Machine photo-6

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

HST

Model Number:

WDW-G

Contact Supplier Request Quote Chat Now

Jinan Hensgrand Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao china

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name HST

Model Number WDW-G

Power Electronic

Usage Universal Testing Machine

WDW-G Computerized Electronic Rupture Creep Testing Machine

Product Description

1. Application:

WDW-G series computerized electronic universal testing machines are designed and manufactured according to ASTM, ISO, DIN, GB and other international standards. Applicable for wide range of material for tension, compression, bending, shearing and low cycle test. Suitable for metal, rubber, plastic, spring, textile, and components testing. It is widely used in the corresponding industries, research and development, test institutes and training centers etc. Configurated with high, low temperature box is able to finish temperature environment test.

2. Main Specifications:

Model	WDW-5	WDW-10	WDW-20		WDW-30	WDW-50		WDW-100
Max. Load	5kN 500kgf 1120lbf	10kN 1000kgf 2240lbf	20kN 2000kgf 4480lbf		30kN 3000kgf 6720lbf	50kN 5000kgf 11200lbf		100kN 10000kgf 22400lbf
Load accuracy	≤±1%
Load range	2%-100% of full scale
Loadresolution	1/200000 of full scale
Disp. resolution	0.01mm
Test speed	0.05-500mm/min						0.05-300mm/min
Tensile space	750mm\|30in			650mm\|25.6in			650mm\|25.6in
Comp. space	750mm\|30in			650mm\|25.6in			650mm\|25.6in
Test width	375mm			400mm			420mm
Temperature range	50°C~300°C
Thermostat specifications	High precision temperature control meter, multilevel PID adjust, interval1°C, accuracy: 0.5°C
Temperaturefluctuation	±1°C
Temperature gradient	Better than 3°C
Heating up time	Room temperature to300°C, less than 50 minutes
Uniform temperature zone length	More than 150mm
Size of oven body	Hearth: depth 650mm×width 240mm×height400mm Overall size:1000mm×390mm×600mm
Material	Stainless steel inner shell, long durability, good anti-corrosion performance
Structure	Large observation window, easy operation, with guide rail
High temperature box power	2kW/AC380V/50Hz
Dimension	730×430×1700mm			755×480×1780mm			825×600×1950mm
Power supply	220V, 1ph, 0.5kW			220V, 1ph, 0.75kW			220V, 1ph, 1kW
Weight (kg)	250kg\|550lb			280kg\|616lb			350kg\|770lb
