YES-100kn 200kn 300kn Digital Display cement compressive testing equipment
1. Application
Digital display compression testing machine mainly used for brick, cement, concrete construction material and other material compression resist testing. Widely used in metallurgy, building materials, space flight and aviation, colleges and universities, R&D institution lines. The test operation and data processing meets standard requirements.
2. Product description:
* Structure: mainly composed by main unit, oil source and measuring control system.
* Measuring control system:The machine adopts hydraulic loading, the electronic testing load. With digital display load, loading rate, keeping maximum load, overload protection and outage data keeping and other.
* Safety protection device: When the test force exceed the 3% of the maximum test force ,overload protection, the oil pump motor stop.
Contact: Alice Zhang Skype: hssdtest What's APP / TEL: +86-15098778967
3. Main Specifications
Model |
YES-100 |
YES-200 |
YES-300 |
Max. Load |
100kN |
200kN |
300kN |
Range of test force |
10-100kN |
20-200kN |
30-300kN |
Test space adjusting mode |
Block adjustment test space |
||
Oil source control structure |
With the host integration design |
||
Control mode |
Manual control loading process |
||
Test class |
1 class |
1 class |
1 class |
Load display accuracy |
±1% |
±1% |
±1% |
Force resolution |
1/10000 |
1/10000 |
1/10000 |
Piston stroke |
80mm |
80mm |
80mm |
Max piston speed |
50mm/min |
50mm/min |
50mm/min |
Max compression space between two plates |
210mm |
210mm |
210mm |
Max distance between two columns |
180mm |
180mm |
180mm |
Working table size |
φ170 mm |
φ170 mm |
φ170 mm |
Dimension luis cruz |
900×450×1400mm |
||
Power supply |
0.75Kw/AC380V |
||
YES-2000 YAW-2000D YES-300 YAW-300D
1.Shipping & delivery: It depends on your requirement. We offer as many shipping options as possible, we have cooperated with some transpotation companies and shipping companies. If you need, we can transport products to our country port or even shipping to your country port.
2. Machine' Packaging: Simulation Aninmatronic Costom Triceratops are covered with air bubble firm before put them into the wood en case, which not only has good shock absorption, impact resistance, heat sealing and also has theadvantages of nontoxic, odorless, moisture corrosion, good transparency ect.
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 20 years focusing on test instruments field,6 years exporting experience.
Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 16 months by HST,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest
problems and complaints in a professional and timely.
Q:What about the product' services and quality?
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need.
products are widely recognized and trusted by users.
♥ More information welcome to contact us now!
And welcome to our company! We display more new design in our showroom.
♥ Main web site: : http://www.
Tel: 86 531-58618759| Fax: 86 531 86113759
cement compressive testing equipment
