Stainless Steel Bar Bend Tester, Bending Testing Machine

Name: Stainless Steel Bar Bend Tester, Bending Testing Machine
Brand: HST or OEM
SKU: 126920107
Availability: InStock

Stainless Steel Bar Bend Tester, Bending Testing Machine thumbnail-1

Stainless Steel Bar Bend Tester, Bending Testing Machine photo-1

US$ 2,000 - 4,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

HST or OEM

Model Number:

GW-40B

Contact Supplier Request Quote Chat Now

Jinan Hensgrand Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name HST or OEM

Model Number GW-40B

Power Electronic

Usage Bending Testing Machine

Specifications

1.CE certificate
2. Display directly bending angle
4. Digital rebar bend testing machine

GW-40B stainless steel bar bend tester

1.Application:

This testing machine can be used to do cold bend and rebend test on plane. The main technical parameters accord with GB1499.2-2007 <The second part of Steel tube for the reinforcement of concrete: hot rolled ribbed steel bars>, YB/T5126-2003 <Program of steel bars plane rebend tests> .This machine is suitable for bend test of the metallic material - rods and bars, the plate, spiral steel, and widely applies in the building materials, the metallurgy, the Scientific research Unit, the universities, colleges and institutes, the quality detection center and the commodity inspection department. It is indispensable ideal testing machines to test the recurvating character and cold bending property of screw thread steel bar .

2.Main specifications:

Mode	GW-40B	GW-50B
Max of bending diam of Steel Bar	40mm	50mm
Forward bending angle	0° to 180°at will
Reverse bending angle	0° to 25°at will
Rotating speed of working table	≤20°/s
Distance between the center of two rolls	165mm	165mm
Diameter of the working table	Φ580mm	Φ760mm
Motor power	1.5kw	2.2KW
Standard bending accessory	HRB-335/φ6-φ40/or other configuration option	HRB-335/φ6-φ50/or other configuration option
Weight	1500kg	2500kg
