universal weld filler metal n06686 2.4606 alloy incoloy686
INCONEL® alloy 686 (UNS N06686/W.Nr. 2.4606) is
a single-phase, austenitic Ni-Cr-Mo-W alloy offering
outstanding corrosion-resistance in a range of severe
environments. Its high nickel (Ni) and molybdenum
(Mo) provide good resistance in reducing conditions,
and high chromium (Cr) offers resistance to oxidizing
media. Molybdenum (Mo) and tungsten (W) aid
resistance to localized corrosion such as pitting. Iron
(Fe) is closely controlled to enhance properties. Low
carbon (C) helps minimize grain boundary precipitation
to maintain corrosion-resistance in the heat-affected
zones of welded joints. Resistance to general, pitting
and crevice corrosion increases with the alloying
(Cr+Mo+W) content, and INCONEL alloy 686 scores
higher than competitive materials. INCONEL alloy 686
is protected by U.S. patent 5,019,184.
Its matched composition welding products,
designated as INCO-WELD® filler metals and welding
electrode 686 CPT® also offer exceptional as-welded
resistance to sulfuric or hydrochloric acids, to mixtures
of the two, and to crevice or pitting corrosion in hot
concentrated acid chloride solutions. These welding
products are also used for dissimilar and overmatched
welding applications (see pages 10 and 11).
INCONEL alloy 686 is used for resistance to
aggressive media in chemical processing, pollution
control, pulp and paper manufacture, and waste
Table 1 - Limiting Chemical Composition, %
Chromium....................................................................19.0-23.0
Molybdenum ...............................................................15.0-17.0
Tungsten..........................................................................3.0-4.4
Titanium.......................................................................0.02-0.25
Iron................................................................................2.0 max.
Carbon........................................................................0.01 max.
Manganese .................................................................0.75 max.
Sulfur ..........................................................................0.02 max.
Silicon .........................................................................0.08 max.
Phosphorus ................................................................0.04 max.
Nickel............................................................................Balance*
1. If we travel to China to checking your facility, are you welcome?
Of course, why not?
we will provide the whole accompany from you landing in China.
Only Give us a call before your arrive.
We will pick up you from the airport, living in our company's hotel, and driving by car take you visiting our company.
Warm Welcome!
2. How many sales person in your team?
present 8 sales, but more hands help in work, total team is 20+ workers.
So do not worry, not the one person company.
3. How Many Years of your company working in this industry?
We are 20+ years, from last century.
Expanding the market, and cultivate our techniques, two ways all in work together.
4. Could you show me some photos of your producing working?
here, following is our working plant, all is same when you come to China to audit.
we are locate in Shanghai. Building 32, No 518 XinZhuan Rd., Songjiang District, Shanghai, China
Postcode: 201601
Not matter where you come from, give us a call, we will pick up from the airport, station, etc.
Welcome take a visiting to our company!
Metro: Line 9, Jiu Ting Station
Train: HongQiao Station (22KM, take taxi 25 mins arriving at our company)
Bus: Shanghai Sourth Station (20KM, take taxi 20 mins arriving at our company)
Airplane:
From: PVG Airport (Shanghai Pudong Airport) only 50~53kilometer, by Taxi 50 mins arriving at our company,
From: Shanghai HongQiao Airport, 22KM, take 25 mins arriving at our company.
Standard export package with water proof paper, and metal pallet, and angle bar protection, and steel strip or as required
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS
