sea water neutral salts brines corrosion resistance incoloy625
Specifications incoloy625
1.nickel welding wire inconel625 W.Nr 2.4856
2. Competitive price;
3. Professional knowledge;
4. Fast delivery;
nickel welding wire inconel625 W.Nr 2.4856
Inconel625, a Nickel-Chromium-Molybdenum alloy with low Carbon and Niobium addition, has superior resistance to high temperature effects such as oxidation and carburization as well as to a wide range of corrosive environments of unusual severity, especially resistance to pitting and crevice corrosion. Typical applications for inconel 625 are seawater applications, aerospace components, chemical processing equipment, nuclear water reaction components.
Chemical Composition incoloy625
Grade |
Ni% |
Cr% |
Mo% |
Nb+Ta% |
Fe% |
Al% |
Ti% |
C% |
Mn% |
Si% |
Cu% |
P% |
S% |
Alloy 625 |
Min 58 |
20-23 |
8-10 |
3.15-4.15 |
Max 5 |
Max 0.4 |
Max 0.4 |
Max 0.1 |
Max 0.5 |
Max 0.5 |
Max 0.5 |
Max 0.015 |
Max 0.015 |
Specifications incoloy625
Grade |
UNS |
Werkstoff Nr. |
Alloy 625 |
N06625 |
2.4856 |
Physical Properties 2.4856
Grade |
Density |
Melting Point |
Alloy 625 |
8.4 g/cm3 |
1290°C-1350 °C |
Minimum mechanical properties in the room temperature incoloy625
Alloy state |
Tensile strength Rm N/mm² |
Yieldstrength R P0. 2N/mm² |
Elongation A 5 % |
Brinell hardness HB |
Alloy 625 |
760 |
345 |
30 |
≤220 |
Alloy625 Grade 2 is recommended for components that require optimum resistance to creep or rupture. Fine-grained (annealed) material may be advantageous at temperatures up to 1500°F with respect to fatigue strength, hardness, and tensile and yield strength.
Welding of incoloy625
Any traditional welding procedures can be used to weld Inconel 625 to similar alloys or other metals, such as gas tungsten arc welding(GTAW), plasma arc welding (PAW), metal inertia gas welding (MIG) and so on. Before welding, remove scale, grease, mark and imprint. And no heat treatment needed before and after welding. Recommend filler wire regarding welding Inconel 625: ERNiCrMo-3
|
|
|
|
1. If we travel to China to checking your facility, are you welcome?
Of course, why not?
we will provide the whole accompany from you landing in China.
Only Give us a call before your arrive.
We will pick up you from the airport, living in our company's hotel, and driving by car take you visiting our company.
Warm Welcome!
2. How many sales person in your team?
present 8 sales, but more hands help in work, total team is 20+ workers.
So do not worry, not the one person company.
3. How Many Years of your company working in this industry?
We are 20+ years, from last century.
Expanding the market, and cultivate our techniques, two ways all in work together.
4. Could you show me some photos of your producing working?
here, following is our working plant, all is same when you come to China to audit.
we are locate in Shanghai. Building 32, No 518 XinZhuan Rd., Songjiang District, Shanghai, China
Postcode: 201601
Not matter where you come from, give us a call, we will pick up from the airport, station, etc.
Welcome take a visiting to our company!
Metro: Line 9, Jiu Ting Station
Train: HongQiao Station (22KM, take taxi 25 mins arriving at our company)
Bus: Shanghai Sourth Station (20KM, take taxi 20 mins arriving at our company)
Airplane:
From: PVG Airport (Shanghai Pudong Airport) only 50~53kilometer, by Taxi 50 mins arriving at our company,
From: Shanghai HongQiao Airport, 22KM, take 25 mins arriving at our company.
Standard export package with water proof paper, and metal pallet, and angle bar protection, and steel strip or as required
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high) about 24-26CBM, 23MTS
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high) about 54CBM, 27MTS
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high) about 68CBM, 27MTS
