Specifications
MC Series single phase asynchronous motor ac1good performance
2safe and reliable operation
3low noise, light vibration
MC Series single phase asynchronous motor ac
Introduce
MC Series Aluminum housing single-phase capacitor start asynchronous motors, with the international latest design, are made of quality materials and meet the relative standards of IEC. They have low noise with little ribration as well as light weight and simple constraction. With their high starting torque MCseries motors have exellent starting performance. the starting torque can be multiples of up to 2.5 times.
This series motors can be used on air compressor, pumps, refrigeration, medical apparatus and instruments, and other machines that need full-load starting.
Ambient temperature:-15°C~40°C
Altitude: not exceed 1000m
Rated voltage: 220V; 110V~240V
Rated frequency: 50HZ/60HZ
Duty:S1(continous)
Insulation class: B/F/H
Protection class: IP54/IP55
Cooling method: ICO141
| Type | Output | Current (A) | Speed (r/min) | EFF. (%) | Power Factor | Tstart/Tn | Ist/In | Tmax/Tn | |
| KW | HP | ||||||||
| MC711-2 | 0.18 | 0.24 | 1.89 | 2750 | 60.0 | 0.72 | 3.0 | 6.5 | 1.8 |
| MC712-2 | 0.25 | 0.33 | 2.40 | 2770 | 64.0 | 0.74 | 3.0 | 6.5 | 1.8 |
| MC801-2 | 0.37 | 0.50 | 3.36 | 2800 | 65.0 | 0.77 | 2.8 | 6.5 | 1.8 |
| MC802-2 | 0.55 | 0.75 | 4.65 | 2810 | 68.0 | 0.79 | 2.8 | 6.5 | 1.8 |
| MC90S-2 | 0.75 | 1.00 | 6.09 | 2820 | 70.0 | 0.80 | 2.5 | 6.5 | 1.8 |
| MC90L-2 | 1.10 | 1.50 | 8.68 | 2820 | 72.0 | 0.80 | 2.5 | 6.5 | 1.8 |
| MC100L1-2 | 1.50 | 2.00 | 11.40 | 2830 | 74.0 | 0.81 | 2.5 | 7.0 | 1.8 |
| MC100L2-2 | 2.20 | 3.00 | 16.50 | 2830 | 75.0 | 0.81 | 2.2 | 7.0 | 1.8 |
| MC112M-2 | 3.00 | 4.00 | 21.60 | 2840 | 76.0 | 0.87 | 2.2 | 7.0 | 1.8 |
| MC711-4 | 0.12 | 0.16 | 1.88 | 1350 | 50.0 | 0.58 | 3.0 | 6.0 | 1.8 |
| MC712-4 | 0.18 | 0.24 | 2.49 | 1370 | 53.0 | 0.62 | 3.0 | 6.0 | 1.8 |
| MC801-4 | 0.25 | 0.33 | 3.11 | 1400 | 58.0 | 0.63 | 2.8 | 6.0 | 1.8 |
| MC802-4 | 0.37 | 0.50 | 4.24 | 410 | 62.0 | 0.64 | 2.8 | 6.0 | 1.8 |
| MC90S-4 | 0.55 | 0.75 | 5.49 | 1420 | 66.0 | 0.69 | 2.5 | 6.0 | 1.8 |
| MC90L-4 | 0.75 | 1.00 | 6.87 | 1420 | 68.0 | 0.73 | 2.5 | 6.0 | 1.8 |
| MC100L1-4 | 1.10 | 1.50 | 9.52 | 1430 | 71.0 | 0.74 | 2.5 | 6.5 | 1.8 |
| MC100L2-4 | 1.50 | 2.00 | 12.50 | 1430 | 73.0 | 0.75 | 2.5 | 6.5 | 1.8 |
| MC112M-4 | 2.2 | 3.00 | 17.80 | 1440 | 74.0 | 0.76 | 2.2 | 6.5 | 1.8 |
