Specifications
single phase capacitor start and run motor ac1.
2.high torque
3.general use
4.fast delivery with nice price
single phase capacitor start and run motor ac
Features:
1. Type: heavy-duty single phase capacitor start and run induction motor ac
2. Construction: totally enclosed, fan cooled, squirrel cage type
3. Insulation: F class
4. Frame and housing is cast iron.
5. Advantage: low noise, low temperature rise, small starting current, high starting torque, reliable operation, easy maintenance and nice appearance.
Operating Conditions:
1. Ambient temperature: -15°C<0 < 40 °C
2. Altitude: not exceed 1000m
3. Duty/Rating: Continuous (S1)
4. Insulation class: B/F
5. Protection class: IP44/IP54
6. Cooling Method: ICO411
Use:
YCL Series motors are suitable for driving small-size turning machine, especially suitable for household and workshop where only single-phase power be supplied.
Technical Data:
| YCL Series Heavy-Duty Single-Phase Capacitor Start and Run Induction Motor | |||||||||
| Type | Output | Current | Power Factor | Eff | Speed | Tstart/Tn | Ist/In | Tmax/Tn | |
| HP | KW | (A) | (cosφ) | (%) | (r/min) | ||||
| YCL80A-2 | 0.5 | 0.37 | 2.7 | 0.94 | 68.5 | 2830 | 2.3 | 6.0 | 1.8 |
| YCL80B-2 | 0.75 | 0.55 | 4.0 | 0.95 | 71.0 | 2840 | 2.4 | 6.0 | 1.8 |
| YCL80C-2 | 1.0 | 0.75 | 5.4 | 0.95 | 72.5 | 2850 | 2.5 | 6.0 | 1.8 |
| YCL90S-2 | 1.5 | 1.10 | 7.2 | 0.95 | 73.2 | 2880 | 2.8 | 6.0 | 1.8 |
| YCL90L-2 | 2.0 | 1.50 | 8.9 | 0.97 | 76.0 | 2900 | 2.8 | 7.0 | 1.8 |
| YCL100L-2 | 3.0 | 2.20 | 13.2 | 0.96 | 78.8 | 2900 | 3.0 | 6.5 | 1.8 |
| YCL80A-4 | 1/3 | 0.25 | 1.3 | 0.93 | 67.0 | 1410 | 2.3 | 6.0 | 1.8 |
| YCL80B-4 | 1/2 | 0.37 | 2.6 | 0.93 | 69.0 | 1420 | 2.4 | 6.0 | 1.8 |
| YCL80C-4 | 3/4 | 0.55 | 3.8 | 0.93 | 71.0 | 1430 | 2.5 | 6.0 | 1.8 |
| YCL90S-4 | 1.0 | 0.75 | 5.0 | 0.93 | 73.3 | 1450 | 2.8 | 6.5 | 1.8 |
| YCL90L-4 | 1.5 | 1.10 | 7.8 | 0.9 | 75.0 | 1450 | 2.6 | 6.0 | 1.8 |
| YCL100L-4 | 2.0 | 1.50 | 9.3 | 0.92 | 79.4 | 1450 | 2.8 | 7.0 | 1.8 |
| YCL112M-4 | 3.0 | 2.20 | 13.6 | 0.9 | 81.6 | 1450 | 2.3 | 6.5 | 1.8 |
| YCL132S1-4 | 4.0 | 3.00 | 18.2 | 0.9 | 83.2 | 1450 | 2.1 | 6.5 | 1.8 |
| YCL132S2-4 | 5.0 | 3.70 | 22.0 | 0.9 | 84.9 | 1450 | 2.1 | 6.5 | 1.8 |
| YCL132M1-4 | 7.5 | 5.50 | 32.5 | 0.9 | 85.0 | 1460 | 2.0 | 6.5 | 1.8 |
| YCL132M2-4 | 10.0 | 7.50 | 40.0 | 0.9 | 85.5 | 1460 | 2.0 | 6.5 | 1.8 |
Our Factory:
Production Line and Test:
Packing and Loading Containers:
