3 Years or 5 Years Warranty, UL, CUL, DLC, TUV, CE, RoHS Replace 300W HID Light 120W LED Pendant Light

Name: 3 Years or 5 Years Warranty, UL, CUL, DLC, TUV, CE, RoHS Replace 300W HID Light 120W LED Pendant Light
Brand: Zhihai
Price: USD $10 - 500 / Unit

FOB Price

USD $10 - $500 / Unit

2 Units(Min.Order)

Supply Ability 7000 Piece / Pieces per Month
Port TianJin
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

LED Light Source:	Osram	Input Voltage(V):	80~315 Vac	Lamp Power(W):	400
Lamp Luminous Flux(lm):	48000	Lamp Luminous Efficiency(lm/w):	120	Color Temperature(CCT):	Cool White
Working Temperature(℃):	-40, 60	Working Lifetime(Hour):	50000	Lamp Body Material:	Aluminum Alloy
IP Rating:	IP67	Certification:	C-tick, CCC, CE, EMC, LVD, SAA, UL	Place of Origin:	Shaanxi, China
Brand Name:	Zhihai	Model Number:	ZHGL-120A

Product Description

-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Product Description

Features & Characteristic:
*Patent multi- function design, suitable for all projects
*5-5-10 year warranty
*Top performance LED chips, 120 lm/w system efficacy
*80% lumen maintenance over 50,000hours
*0-10Vdc dimming driver available
*Photocell and motion sensor system available
*Built-in surge protection
*Built-in thermal protection
*Maintenance free
*Mercury free, No UV or IR
*Universal 80-347Vac input without additional adapter
*Instant start and flicker free
*High uniformity and color rendering

Dimensions:

Description:

Model		ZHGL-30A	ZHGL-60A	ZHGL-90A	ZHGL-120A	ZHGL-150A	ZHGL-180A	ZHGL-210A	ZHGL-270A
Power Consumption	LEDs	25W	50W	80W	108W	135W	162W	189W	243W
	Driver	5W	10W	10W	12W	15W	18W	21W	27W
	Total	30W	60W	90W	120W	150W	180W	210W	270W
Initial Lumen Lamp(6000K)		3600 lm	7200 lm	10800 lm	14400 lm	18000 lm	21600 lm	25200 lm	32400 lm
Replace HID Lamp		50-100W	100-150W	150-250W	250-300W	300-400W	400-500W	500-600W	600-1000W
Dimension		360x323x163mm
Net Weight		8kg (17.6lbs)
Color Temperature		4000K - 6000K
Color Rendering		≥Ra75
Working Life		≥50000Hrs
Housiong Material		Aluminum
Coating		Zinc Rich Paint
IP Class		IP 65 (Upgradeable to IP 67)
Insulation Class		Class I (Upgradeable to Class II)
Working Temperature		-40C ~ 60C / -40F ~ 140F
Working Humidity		10% ~ 95%
AC Input		80 ~ 315Vac, (347Vac available on request)
DC Input		80 ~ 400Vdc, (12Vdc, 24Vdc and other input available on request)
THD		<10%
Power Factor		≥0.98
Warranty	LED Module	5 year
	Driver	5 year
	Housing	10 year

Beam Angle Options:

Flexible Multi-function Design Mounting Brackets:

Installation:

Beam Spread:

Certificates:

Projects:

Trade Shows

Packaging & Shipping

Model	N.W (KGS)	G.W (KGS)	CTN SIZE (MM)	PCS/CTN
ZHGL-30A	8.1	12/13.5	430430320	1
ZHGL-60A	8.1	12/13.5	430430320	1
ZHGL-90A	8.1	12/13.5	430430320	1
ZHGL-120A	8.1	12/13.5	430430320	1
ZHGL-150A	8.1	12/13.5	430430320	1
ZHGL-180A	8.1	12/13.5	430430320	1
ZHGL-210A	8.1	12/13.5	430430320	1
ZHGL-270A	8.1	12/13.5	430430320	1
