Welcome To Eastwin
1:Our OEM PCB board manufacture and SMT PCB Assembly service
* PCB board file with parts list provided by customers
* PCB board made, circuit board parts purchased by us
* PCB board with parts assembled
* Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
* Fast delivery, anti-static package
* RoHS Directive-compliant, lead-free
* Custom clearance for material importing and product exporting
2:Eastwin PCB assembly Equipment:
· SMT Machine: SIEMENS SIPLACE D1/D2 / SIEMENS SIPLACE S20/F4
· Reflow Oven: FolunGwin FL-RX860
· Wave Soldering Machine: FolunGwin ADS300
· Automated Optical Inspection (AOI): Aleader ALD-H-350B
· Fully Automatic SMT Stencil Printer: FolunGwin Win-5
3: Eastwin SMT Production Flow:
Material Receiving → IQC → Stock → Material to SMT → SMT Line Loading → Solder Paste/Glue Printing → Chip Mount → Reflow → 100% Visual Inspection → Automated Optical Inspection (AOI) → SMT QC Sampling → SMT Stock → Material to PTH → PTH Line Loading → Plated Through Hole → Wave Soldering → Touch Up → 100% Visual Inspection → PTH QC Sampling → In-Circuit Test (ICT) → Final Assembly → Functional Test (FCT) → Packing → OQC Sampling → Shipping
4:Requested information for PCB assembly:
· Gerber file of the bare PCB board (Gerber file,Eagle file,PCB file,etc)
· BOM (components list) for assembly,Schematic if necessary
· Programming files & Programming tool if necessary
· Testing Guide & Test Fixtures if necessary
· Clear picturers of pcba or pcba samples for us
· Please kindly advise us if there is any acceptable components substitution.
5.Eastwin PCB Fabrication Capabilities
No |
Items |
PCB Fabrication Capabilities |
1 |
Number of Layer |
1,2,4 or 6,upto 18 layer |
2 |
Base Material |
FR4, CEM-1, CEM-3, Aluminium, High Tg, Rogers |
3 |
Order Quantity |
1 to 50,000 |
4 |
Board Shape |
Retangular,round,slots,cutouts,complex,irregular |
5 |
Board Type |
Rigid, Flexible, Rigid-flexible |
6 |
Board Cutting |
Shear,V-score,Tab-routed |
7 |
Board Thickness |
0.2-4.0mm, Flex 0.01-0.25mm |
8 |
Copper Weight |
1.0, 1.5, 2.0 oz |
9 |
Solder Mask |
Red,White,Yellow,Blue,Black(Double/single side) |
10 |
Silk Screen |
White,Yellow,Blue,Black,Red(Double/single side) |
11 |
Silk Screen Min Line Width |
0.006'' or 0.15mm |
12 |
Max Board Dimensions |
20 inch*20inch or 500mm*500mm |
13 |
Min Trace/Gap |
0.10mm, or 4mils |
14 |
Min Drill Hole Diameter |
0.01'',0.25mm, or 10mils |
15 |
Surface Finish |
HASL,Nickle,ENIG,ImmersionTin/Silver,OSP,etc. |
16 |
Board Thickness Tolerance |
±10% |
17 |
Copper Weight Tolerance |
± 0.25 oz |
18 |
Minimal Slot Width |
0.12'', 3.0mm, or 120mils |
19 |
V-Score Depth |
20-25% of board thickness |
20 |
Design File Formate |
Gerber RS-274,274D,Eagle and AutoCAD's DXF,DWG |
6.Testing Procedures For PCB Board
---We perform multiple quality assurance procedures before shipping out any PCB board. These include:
· Visual Inspection
· Flying probe
· Bed of nails
· Impedance control
· Solder-ability detection
· Digital metallograghic microscope
· AOI (Automated Optical Inspection)
7:Packaging:
Inner packing :Vacuum Package Outer packing:Standard Carton
---Finished boards are vacuum packed with bubble wraps and silica gel to prevent oxidization and damage duringtransportation.All the PCB will be checked before shipping.
8.Payment Terms:TT&Paypal In Advance
9.Lead Time For PCB and PCBA
PCB Board:5-7 days
PCBA:20-25 days
Samples for Approval before mass production.
