Kingdom cnc hydraulic shearing machine
Specifications
CE and ISO,
Light device on the line
Adjustable cutting angle
| Model |
Shearing size (T x W) |
Shearing Angle (°) |
Max. Stroke per min |
Back Gange Range |
Electric Power (kW) |
Machine Dimension (L x W x H) |
| 4 x 2500 | 4 x 2500 | 1.5 | 18 | 20-500 | 4 | 2960 x 1380 x 1500 |
| 4 x 3200 | 4 x 3200 | 1.5 | 14 | 20-600 | 7.5 | 3600 x 1650 x 1620 |
| 4 x 4000 | 4 x 4000 | 1.5 | 12 | 20-600 | 7.5 | 4500 x 1900 x 1800 |
| 4 x 5000 | 4 x 5000 | 1.5 | 10 | 20-600 | 7.5 | 5700 x 2100 x 2200 |
| 6 x 2500 | 6 x 2500 | 1.5 | 16 | 20-600 | 7.5 | 2900 x 1600 x 1620 |
| 6 x 3200 | 6 x 3200 | 1.5 | 14 | 20-600 | 7.5 | 3700 x 1650 x 1680 |
| 6 x 4000 | 6 x 4000 | 1.5 | 12 | 20-600 | 7.5 | 4500 x 1900 x 1800 |
| 6 x 6000 | 6 x 6000 | 1.5 | 8 | 20-600 | 11 | 6700 x 2200 x 2200 |
| 8 x 2500 | 8 x 2500 | 1.5 | 144 | 20-600 | 11 | 2960 x 1650 x 1700 |
| 8 x 3200 | 8 x 3200 | 1.5 | 12 | 20-600 | 11 | 3700 x 1650 x 1700 |
| 8 x 4000 | 8 x 4000 | 1.5 | 8 | 20-600 | 11 | 4480 x 1800 x 1700 |
| 8 x 5000 | 8 x 5000 | 1.5 | 6 | 20-600 | 11 | 5700 x 2250 x 2310 |
| 10 x 2500 | 10 x 2500 | 1.5 | 10 | 20-600 | 11 | 3200 x 1800 x 1700 |
| 10 x 3200 | 10 x 3200 | 1.5 | 10 | 20-600 | 11 | 3900 x 1950 x 1900 |
| 10 x 4000 | 10 x 4000 | 1.5 | 8 | 20-600 | 18.5 | 4700 x 2200 x 2100 |
| 10 x 6000 | 10 x 6000 | 1.5 | 6 | 20-600 | 18.5 | 6700 x 2500 x 2450 |
| 12 x 2500 | 12 x 2500 | 1°40′ | 11 | 20-600 | 15 | 3200 x 2060 x 1960 |
| 12 x 3200 | 12 x 3200 | 1°40′ | 10 | 20-600 | 18.5 | 3900 x 2127 x 2100 |
| 12 x 4000 | 12 x 4000 | 1.75 | 8 | 20-600 | 18.5 | 4700 x 2250 x 2100 |
| 12 x 6000 | 12 x 6000 | 1.75 | 5 | 20-600 | 22 | 6700 x 2700 x 2750 |
| 12 x 8000 | 12 x 8000 | 1.75 | 5 | 20-600 | 22 | 9100 x 3400 x 2900 |
| 16 x 2500 | 16 x 2500 | 2.5 | 8 | 20-600 | 18.5 | 2900 x 2127 x 2000 |
| 16 x 3200 | 16 x 3200 | 2.5 | 7 | 20-600 | 22 | 4000 x 2400 x 2100 |
| 16 x 4000 | 16 x 4000 | 2.5 | 6 | 20-600 | 22 | 4700 x 2500 x 2300 |
| 16 x 6000 | 16 x 6000 | 2.5 | 6 | 20-600 | 30 | 6700 x 3300 x 2750 |
| 20 x 2500 | 20 x 2500 | 2.5 | 6 | 20-600 | 30 | 3200 x 2450 x 2150 |
| 20 x 3200 | 20 x 3200 | 2.5 | 5 | 20-600 | 30 | 3900 x 2500 x 2200 |
| 20 x 4000 | 20 x 4000 | 2.5 | 4 | 20-600 | 37 | 4800 x 2600 x 2400 |
| 20 x 6000 | 20 x 6000 | 2.5 | 4 | 20-600 | 37 | 6700 x 3200 x 2860 |
| 25 x 2500 | 25 x 2500 | 3 | 4 | 20-600 | 37 | 3500 x 3000 x 2300 |
Introduction:
1, Sheet plate welded structure is adopted, with hydraulic transmission and accumulator return, typical of an easy operation, reliable performance, and nice appearance.
2, Indication by indicator is provided for adjustment of blade clearance, for a handy and prompt adjustment.
3, Alignment device with lighting and control device for shearing stoke bar and to reduce frictional resistance.
4, Rolling material support ball is provided, to minimize fish tail with sheet bar and to reduce frictional resistance.
5, The rear stopper is fitted with electric adjustment and manual adjustment devices, and digital device is available for display if size of stopper and times of shearing
6, The rear stopper is fitted with coder and digital display system, So that the position of rear stopper is displayed more accurately, thus to further enhance the shearing precision if this machine.
Features:
1. Motor: Siemens, Germany
2. Main Electric Components: Schneider, French
3. Seal in the Cylinders: NOK, Japan
4. Valve: Atos, Italy
5. Pump: Sumitomo, Japan
6. Wiring Terminal Block: WEIDMULLER, Germany
7. NC Control System: Estun E21, China
Photos:
Training After-sales Service:
1. Technical documents
All labels on machines and lay-out drawings, Electrical diagram, Operation Manual, will be in English. The seller should send all necessary files to the buyer since the third week since project execution. All documents in hard copies should be also shipped with machines together.
2. Arrangement for inspection, installation and testing work
a. After all machines are delivered to customer’s factory; Buyer is responsible for all preparation work, e.g. electricity supply, water supply, labors and cranes, etc.
b. The buyer will prepare for visa application for their engineers, who are responsible for guide of machine installation and testing at the Buyer’s factory.
c. The Buyer will buy the round-trip air ticket for Engineer if visa application is approved. The buyer is also responsible to bear expenses generated, e.g. visa formalities, meals, accommodation and allowance of USD80 per day for each engineer.
d. Engineer will give free training lessons to labors in buyer’s factory.
3. Quantity and quality guarantee
a. Quantity/Quality Discrepancy to destination port during transportation
In case of quality/quantity discrepancy to destination port in transportation, the buyer should file claim within 30 days after the arrival of the goods at port of destination. The seller will not be responsible for any discrepancy of the goods caused by shipping company and other transportation organization and/or post office.
b. Guarantee period and after-sales services: 13 months since date of bill of lading
During this guarantee period, the seller will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by your incorrect operations, the seller will provide the buyer spare parts at cost price.
c. Long-term service
The seller will charge the buyer cost price of spare parts beyond one year and provide long-term technical guide.
Payment Terms:
T/T, L/C at sight are acceptable by us.
Guarantee period:
Our product quality guarantee period is 13 months from B/L date. During guarantee period, we will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by customers’ incorrect operations, we will provide customers spare parts at cost price. We also can offer flexible extended warranties according to the actual situation.
After-sales services:
Our engineer can go to your factory for installation and showing operation details on condition of you provide the round-trip air tickets, visa formalities, food and accommodation. In turn, your engineers can come to our factory for learning the installation, operation and maintenance for free.
Why Choose Us:
1. We will run the machine for a few days, and use your materials to do the test. Only guarantee the machine shows best performance, and then we will ship out.
2. Our elite teams can provide you professional, customized, and all-round services around the clock. If you need any help, contact us by WHATSAPP, Skype, Email or Telephone.
How can we provide you efficient services (metal processing solution):
There are Three Steps as following:
1. Gather your requirements based on your real working situation.
2. Analyze your information and provide our feedback.
3. Offer options based on your specific needs. For instance, reg. standard products, we can offer professional recommendations; reg. non-standard products, we can offer professional designing.
