Home > Industrial Equipment & Components > Fastener & Fitting > Flange > Grinding Media Balls With Long Service Life

Grinding Media Balls With Long Service Life

US$ 12 - 49 MOQ: 15 Kilograms

Key Specifications

Get Latest Price

Place of Origin:

Hunan, China

Brand Name:

TDC

Model Number:

various

Contact Supplier Request Quote Chat Now

Zhuzhou Tongda Carbide Works

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou Shanghai Shenzhen Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hunan, China

Brand Name TDC

Model Number various

Application widely, precision bearings, instruments, pens, spraying machines, pumps

Dimensions different diameter

Specifications

Grinding Media Balls With Long Service Life
1 The nice wear part of balls
2 OEM,ODM was accepted
3 ISO9001 certificate

Grinding Media Balls With Long Service Life

Specification

1.Professionl manufacturer for tungsten carbide items with more than 12 years

2.ISO 9001-2008 Quality Control System

3.OEM, ODM project accepted

Grinding Media Balls With Long Service Life

Brief introduction

Tungsten carbide ball is also called hard alloy ball. It is used for applications requiring extreme hardness and resistance to wear and abrasive, hard shocks and impacts. The application include special valves, flow meters, recirculating balls bearing screws, liner bearing and balls for ball point pens. They are also used often for mining, as pi vols and points of compactions. They are als used for measurements and calibrations of holes and measurement checking devices.

Pictures show

Set with ball grinding jar

Detailed grade information

Grade	Density g/cm3	Hardness HRA(hv)	T.R.S(M Pa)	Performances &applications recommended
YG6	14.9	89.5	2150	Good Wear resistance, used for hard wood,processing original wood, aluminum section bar,brass rod and cast iron.
YG8	14.6	89	2320	Suitable for the roughening of cast iron and light alloys and also for the milling of cast iron and low-alloy steel.
YG11	14.4	87.5	2260	Medium grain, for wear parts and mining tools
YG15	14.1	86.5	2400	Medium grain, for mining tools, cold heading and punching dies

Physical Property

Grade	Density (g/cm³)	Hardness (HRC)	Tensile Strength (MPa)	Elongation (%)	Toughness (MJ/m²)
W273	17.10±0.15	≥23	≥900	≥24	≥1.30
W263	17.25±0.15	≥23	≥900	≥23	≥1.20
W253	17.40±0.15	≥24	≥900	≥22	≥1.10
W243	17.60±0.15	≥24	≥920	≥20	≥0.90
W232	18.10±0.15	≥25	≥920	≥14	≥0.45
W231	18.30±0.15	≥26	≥920	≥12	≥0.30
W221	18.50±0.15	≥27	≥920	≥10	≥0.22
WNiCu	16.00-18.50	≥22	≥450	2-8	-

Zhuzhou Tongda Cemented Carbide Works

Brief Introduction

Zhuzhou TongDa Cemented Carbide Works specialize in the production of bespoke Tungsten Carbide Hard Metal Wear Resistant Products for use across a wide range of industrial applications in both the as-sintered and finished ground condition.

Established in 2001 Zhuzhou TongDa Cemented Carbide Works are offering customers recommendations and solutions for individual wear resistant components and special tooling requirements.

Zhuzhou TongDa Cemented Carbide Works produce an extensive range of tungsten carbide grades in-house including the popular ISO application grades of K10, K20, K30, K40, P10, P20 & P30/40 as well as numerous special Cobalt and also Nickel binder tungsten carbide grades for use in corrosive resistant applications.

Material compositions including submicron, medium and coarse grain grades are available and can be supplied in cylindrical and flat section in both the as-sintered and finished ground condition.

The tungsten carbide grade powders are processed in-house using quality raw materials to ensure a high product quality is maintained. Individual items and volume production components can be produced by either pre-shaping or automatic press tooling.

Production Process

Certificate

Payment and Shippment way

PRODUCTS RANGE

l Rods & Endmill

l Stripes & Plates

l cutting tools

l Ring & Roller

l Solutions for Polyolefins Industry

l Application in Coating Industry

l Wear parts of Concrete Pump

l Products for mining industry
