HARVEST Hooked-ends Stainless Steel Fibre For Concrete, ASTM A820 Standard
Type : W-304/15/.40HE
Materials : Stainless Steel Grade : 304
Chemical Analysis :
Stainless Steel |
Chemical Analysis (%) |
|||||||
C |
Si |
Mn |
P |
S |
Cr |
Ni |
||
Grade |
304 |
0.08 |
1.0 |
2.0 |
0.045 |
0.030 |
18-20.00 |
8-10.50 |
Typical Dimensions & Aspect Ratios :
|
Length (mm) |
Diamerter (mm) |
Aspect Ratio |
Shape |
Tensile Strength (Mpa) |
No/kg (approx.) |
10 |
0.2 |
50 |
Straight |
1450 Min. |
404900 |
15 |
0.2 |
75 |
Straight Hooked Ends Ripple |
269900 |
|
20 |
0.4 |
50 |
50600 |
||
20 |
0.5 |
40 |
32400 |
||
25 |
0.4 |
62.5 |
40500 |
||
25 |
0.5 |
50 |
25900 |
||
30 |
0.4 |
75 |
33700 |
||
30 |
0.5 |
60 |
21600 |
*Other fibre length can be manufactured on request;
*Other fibre diameter can be manufactured on request.
Applications:
HARVEST Hooked-ends Stainless Steel Fibre For Concrete, such as :
- 1. Metallurgical Industry;
- 2. Petrochemical Industry;
- 3. Cement, Glass, Ceramic Industry;
- 4. Energy Industry;
- 5. Other industry furnaces and kilns.
Using method & Using quantity:
HARVEST Hooked-ends Stainless Steel Fibre For Concrete,
l The mixing ratio of stainless steel fibre with refractory matrix is about 1-5% by weight.
Health & Safety:
HARVEST Hooked-ends Stainless Steel Fibre For Concrete,
l USING STEEL FIBRES UNDER NORMAL CONDITIONS DOES NOT PRESENT AN INHALATION, INGESTION OR CONTACT HEALTH HAZARD.
l BECAUSE OF THEIR PHYSICAL NATURE, WE RECOMMEND THAT OPERATIVES HANDLING THE FIBRES SHOULD ALWAYS WEAR GLOVES.
l TO AVOID DETERIORATION OF PACKING, THE FIBRES SHOULD BE STORED IN A DRY ENVIRONMENT.
