How Much is the 100 Mesh Sand Making Machine Machine

Specifications

VSI Sand Maker is a newly researched equipment, with international advanced level.

VSI High Efficiency sand maker(VSI crusher) is the top preferred equipment in artificial sand making and stone reshaping industry.

VSI sand maker is specially suitable for making qualified stone and sand for highway,high-speed railway,high  buliding,hydropower dam construction,concrete mixing station.

VSI Sand Maker Characteristics:

1. Advanced double-pump oil lubrication system guarante shaft bearing lower temperature increase, longer life time, more reliable operation.

2. Main shaft is equipped with imported precision rolling bearing. It makes main shaft work stable, lengthen maintenance cycle, increase productivity.

3. Hydraulic lifting mechanism of upper cover can move away the cover easily, which saves man power during maintenance.

4. Over-vibration device is equipped. There will be alarm when vibration surpasses a stipulated figure. It will stop the machine, in order to protect it.

5. Special dust-proof design for main shaft bearing fully avoid dust entering bearing lubrication part, which make sure the machine work normally.

6. Special feed opening structure make it possible that center feeding and ring feeding comes together, in order to meet requriement of different stones. In addition, this equipment can not only crush stone, but also iron.

7. Shape of material-throughing device is better designed, which improve the utilization ratio.

VSI Sand Maker Usage:

VSI Sand Maker is widely used for artificial sand, in metal and non-metal ores, cement, refractory material, bauxite, silicon carbide, glass material, building material.

VSI Sand Maker Working Principle:

(1) Center Feeding:
Raw material falls down into feed hopper, then enter into impellor through central entrance hole. It is accelarated in high-speed impellor, then is thrown out at speed of 60-75m/s. When it hits impact plate, it is crushed. Final products come downwards though outlet.

(2) Ring Feeding:
Raw material falls down into feed hopper, then through ring, it is divided into two divisions by material-deviding plate. One enters into impellor through the center of material-deviding plate. The other falls down from outside of material-deviding plate. Material, which is thrown out by impellor at speed of 60-75m/s, hits material coming down from outside of material-deviding plate. In this way, material is crushed.


Models: VSI7611~VSI1140
Model: VSI7611
Capacity (t/h): center and ring feeding: 120 ~ 180;center feeding: 60 ~ 90
Max feed size (mm): soft material:below 35; hard material:below 30
Rotation speed (r/min): 1700 ~ 1890
Power for double motor (kw): 110 ~ 150
Overall dimensions  (L×W×H) (mm): 3700 ×2150 ×2100
Weight (t):7.8
Power Source: 380v 50Hz

Model: VSI8518
Capacity (t/h): center and ring feeding: 200 ~ 260; center feeding:100 ~ 130
Max feed size(mm):soft material:below40; hard material:below 35
Rotation speed (r/min): 1520 ~ 1690
Power for double motor (kw): 180 ~ 220
Overall dimensions  (L×W×H) (mm): 4140 ×2280 × 2425
Weight(t):10.3
Power Source: 380v 50Hz

Model:VSI9526
Capacity (t/h): center and ring feeding: 300 ~ 380;center feeding: 150 ~ 190
Max feed size(mm): soft material: below45; hard material: below 40
Rotation speed (r/min):1360 ~1510
Power for double motor (kw): 264 ~ 320
Overall dimensions  (L×W×H)(mm): 4560 ×2447 ×2778
Weight(t) :16
Power Source: 380v 50Hz

Model: VSI1140
Capacity (t/h):center and ring feeding:450 ~ 520;center feeding:225 ~ 260
Max feed size (mm): soft material: below50;  hard material: below 45
Rotation speed (r/min): 1180 ~ 1310
Power for double motor (kw): 400 ~ 440
Overall dimensions  (L×W×H) (mm): 5000 ×2700× 3300
Weight(t): 25.6
Power Source: 380v 50Hz

Notice: Any change of VSI Sand Making Machine technical data shall not be advised additionally
