Factory Price AB Two Component Glue Automatic Mixing Robot dispenser Machine 400*400*100mm High Precision
Product Details for MD-400 Dispenser Robot
1,Model:MD-400
2, WorkingDimension: 400*400*100mm
3, Brand Name: MINGDA
4, Weight: 105kg
Product features for MD-400 dispenser robot
1. Continuous dispensing function for any irregular curve, 3-dimensional dispensing.
2. Take advanced Japanese stepper motor, higher speed and low noise.
3. With static eliminator ,can control the electrostatic within ±100V
4. Automatical dispensing compensation function of dispensing makes it more convenient to operate.
5. Area of XY arrays, rotation of translation function, antistrophe material plate, appliable to different location
Parameters:(MD-400 CNC Robot Glue Dispensing Machine)
Model |
MD-200 |
DM-300 |
MD-400 |
X,Y,Z working range |
200/200/50mm |
300/300/100mm |
400/400/100mm |
Max load-bearing Y/Z |
5kg/3kg |
10kg/5kg |
|
X,Y/Z moving speed |
0.1-600/250 mm/s |
||
Resolution |
0.001mm/ axis |
||
Repetitive accuracy |
±0.01mm/ axis |
||
Program capacity |
At least 100 group, 400 points per group |
||
Display |
Teach pendant LCD |
||
Transmission method |
Synchronous belt + precision guide way |
||
Motor system |
Micro stepper precision motor |
||
Control method |
Point to point & Continuous |
||
Interpolation function |
3 axis(3 dimensional) |
||
Programming method |
Teach pendant |
||
I/O signal port |
8 input/ 8 output |
||
External control |
RS232 |
||
Power supply |
AC110V/220V 350W |
||
Working temperature |
10°C-40°C |
||
Working relative humidity |
20%-90% condensation |
||
Dimension |
325x345x420mm |
520x485x610mm |
620x585x610mm |
Weight |
65kg |
80kg |
105kg |
Application for MD-400 dispensing robots
semiconductor encapsulation, PCB parts fixed and protection, LCD glass machine encapsulation and stick, mobile phone board, speaker assembly line, battery box, auto parts gelatinization, hardware components seal, quantitative liquid filling, chip binding etc.
The main application areas : Mobile Phone , Compture housings , Optical drives , Printers , ink clips , PCB , LCD , LED , DVD , Digital Cameras , Switchs , Connectors , Relays , radiator, semiconductors and other electronics, or SMT devices to connect quickly points / glue, clocks, toys, medical equipment and other required liquid dispensing products .
Appliable glue for MD-400 dispensing robots
UV glue, AB glue, epoxy glue, white glue, EMI conducting resin, Silicon glue,
Instantaneous glue, red glue, silver glue, solder paste, thermalgrease, transparent paint, Screw glue etc.
Accessories of MD-400 dispenser robots
(valves , containers , syringes , dispensing needles and so on)
Parts of MD-400 dispenser robots
Wooden Package of MD-200 dispenser robots Wooden Package
Feedback about our robot dispenser machine
Dear Customers , We are the professional manufacturer for robot dispenser machine , We have sold many this machine to our foreign customers , they also provide good feedback to us .
If you like our machine , Pls do not hesitate to contact with us .
Thanks in advance .
