Help CenterDoor Access Control Controller Waterproof IP68 Metal Case RFID Reader Keypad /SY5000W
Related Products
-
Metal CASE Card Reader Keypad Standalone Rfid Access ControllerNegotiableMOQ: 1 Piece -
Popular DIY Z-WAVE ZigBee Smart Home Kit Sensors for Home AutomationUS$ 10 - 200MOQ: 1 Piece
-
2015 Smart House Control Home Automation System Domotics Smart Control Switch Zigbee Gateway WirelessUS$ 80 - 100MOQ: 1 Piece
-
Smart Home Hub/gateway With Wifi Home Control System,APP Remote ControlUS$ 100 - 150MOQ: 1 Piece
-
Zigbee Smart Home Automation System With Environment Monitor Including Zigbee Temperature Sensor, PM2.5US$ 150 - 200MOQ: 1 Piece
Features:
Waterproof, conforms to IP68
Classical appearance with useful function
High quality and high security
Strong Zinc Alloy Electroplated anti-vandal case
Designed for home and office
Sensitively and response quickly
Full programming from the keypad
Easy to install and program
Support 2000 standard users
Fast operating speed, <20ms with 2000 users
Built-in proximity card reader
Built-in keypad for PIN code entry
Backlight keys
Supports Card, PIN, Card + PIN
Wiegand 26 output for connection to a controller
Lock output current short circuit protection
Very low power consumption (30mA)
Can add card number and delete card number as your requirement
Alarm function
With lock relay output, secure / normal Mode, NO / NC output
Internal buzzer
Built-in bell button can connect a external bell
Important Notice:
Please note that "exit button", "electric lock" and "DC 12V power supply" are not included in this package, please kindly refer to our store for all available accessories for Access Control.
Specifications:
Environment :Conforms to IP68
User Capacity : 2000
Card Reading Distance : 3 ~ 6 cm
Compatible Cards :EM4100 standard cards
Wiegand Interface : Wiegand 26 bit
Lock Output Load < 3 A
Alarm Output Load < 20 A
Wiring Connections : Electric Lock, Exit Button, External Alarm
Adjustable Door Relay time : 0 ~ 99 seconds
Adjustable Alarm Time : 0 ~ 3 minutes
Operation Temperature : -45°C ~ 60°C
Input Voltage :DC 12V
Input Current :- Standby : < 30mA (not including attached devices)
- Active Current : < 60mA (not including attached devices)
Operating Humidity :10% ~ 90% RH
Dimension :
Approx. 120 (W) x 58 (H) x 22 (D) mm
Approx. 4-3/4” (W) x 2-1/4” (H) x 7/8” (D) inch
Package includes:
1 x Waterproof Door Access Control RFID Reader with Keypad Metal Case
1 x Installation Kit
1 x Installation Fixed Label
1 x User Manual
