Optical Turnstile Pedestrian Barrier Gate Flap Barrier Gate With TCP/IP And RFID Reader

Optical Turnstile Pedestrian Barrier Gate Flap Barrier Gate With TCP/IP And RFID Reader thumbnail-1
Optical Turnstile Pedestrian Barrier Gate Flap Barrier Gate With TCP/IP And RFID Reader photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KATM
Model Number:
KATM-230
Contact Supplier Request Quote Chat Now
Shenzhen Keene Engineering Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name KATM
Model Number KATM-230

 Automatic flap barrier with fingerprint access control

Tehcnical Parameters:



Dimension 600*300*1000mm
Stainless Steel Specification                              Body: SS304
Channel Width no more than 600mm
Power Supply AC110V±10V,60Hz / AC220V±10V,50Hz

Drive motor

Brushless DC motor 24V

Communication interface

RS485 electrical standard or TCP/IP
Passing Speed

40 persons/min (normal open)

30 persons/min (normal close)
Response Time 1s
    Input Interface +12V electrical signal or DC impulse signal with width >100ms
Communication Interface RS485/relay signal
Operating Temperature -15°C ~ 50°C
Related Humility <=95%
Package  Paper Carton/Wooden Box







Functions and features:



1. Designed reasonable and reliable movement, noise, smooth running, and long service life.



2. Access Prompt function:Red and green light prompt the passing information.



3. The programmable gates control state, with a variety of operating modes you can choose, you can set a one-way or two-way control



4. Installation with personalized interface, compatible with IC, ID cards and other smart cards.



5. Power failure emergency function after power channel automatically open, closed automatically after power-on, to meet the special needs

 of the user and the fire safety requirements



6. The control panel with counting function, LED digital display function (optional)



7. The standard input and output interface, is the best choice for system integrators



8. With automatic reset function,namely to obtain permission lock after the set time.There is no lock,swing gates automatic cancellation of this

 authority back to the initial state.(the standard is gate turns on 5 seconds will be automatically reset)



9. Pinch, anti bumps function, Blockage when in the process of the swing arm reset within a predetermined time, click stop working automatically,

the default reset again after a delay, and the intensity is very small(2kg)



10. Sound, light alarm function: with trespassing, trailing alarm



11. Scour protection function ,when the gate signal is not received, the stick is automatically locked



12. Fault detection and alarm function, user-friendly maintenance and use
