Automatic Pedestrian Access Control Half Height Swing Door Gate Turnstile Gate Control Remote

Automatic Pedestrian Access Control Half Height Swing Door Gate Turnstile Gate Control Remote photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KATM
Model Number:
KATM-0126
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name KATM
Model Number KATM-0126

Automatic Access Control Swing Barrier:



Tehcnical Parameters:



Dimension diameter 168*1050mm
Stainless Steel Specification                              Body: SS304
Brake rod length 600-900 mm
Power Supply AC110V±10V,60Hz / AC220V±10V,50Hz

Drive motor

Brushless DC motor 24V

Communication interface

RS485 electrical standard or TCP/IP

Passing Speed

40 persons/min (normal open)

30 persons/min (normal close)

Response Time 1s
    Input Interface +12V electrical signal or DC impulse signal with width >100ms
Communication Interface RS485/relay signal
Operating Temperature -15°C ~ 50°C
Related Humility <=95%
Package  Paper Carton/Wooden Box







Functions and features:



1. Designed reasonable and reliable movement, noise, smooth running, and long service life.



2. Access Prompt function:Red and green light prompt the passing information.



3. The programmable gates control state, with a variety of operating modes you can choose, you can set a one-way or two-way control



4. Installation with personalized interface, compatible with IC, ID cards and other smart cards.



5. The main control panel built small button, the device can be set to run state



6. Pinch, anti bumps function, Blockage when in the process of the swing arm reset within a predetermined time, click stop working automatically,

the default reset again after a delay, and the intensity is very small(2kg)



7. Scour protection function ,when the gate signal is not received, the stick is automatically locked



8. With automatic reset function,namely to obtain permission lock after the set time.There is no lock,swing gates automatic cancellation of this

authority

back to the initial state.



9. Normally open or closed can be freely adjusted to meet different venue requirements



10. Can be mounted with a variety of reading devices, the receiver relay switch signal



11.Single ,bi-directional swing function, one-way or two-way control personnel access



12.Directly through the management computer for remote control and management, auto-reset delay automatic reset, the system default is 10

seconds

after opening (adjustable)



13.Power failure emergency function after power channel automatically open, closed automatically after power-on, to meet the special needs

of the user

and the fire safety requirements

Automatic Pedestrian Access Control half height swing door gate turnstile gate control remoteAutomatic Pedestrian Access Control half height swing door gate turnstile gate control remoteAutomatic Pedestrian Access Control half height swing door gate turnstile gate control remoteAutomatic Pedestrian Access Control half height swing door gate turnstile gate control remote
