Home > Computer Products > Network Hardware & Parts > Router > Cisco ASA 5520 ASA5520-AIP20-K9

Cisco ASA 5520 ASA5520-AIP20-K9

Cisco ASA 5520 ASA5520-AIP20-K9 photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Wired
VPN Support:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Products Status Stock
Type Wired
VPN Support Yes
Certification CE
Brand Name CISCO
Model Number ASA5520-AIP20-K9
Place of Origin China

Specifications

1. Cisco ASA 5520 ASA5520-AIP20-K9
2. Original Packing
3. 1 year warranty
4. Big discount and fast delivery



Cisco ASA 5520 ASA5520-AIP20-K9



Specifications

 Cisco ASA 5520 ASA5520-AIP20-K9

 ASA 5520 Appliance w/ AIP-SSM-20, SW, HA, 4GE+1FE, 3DES/AES



Cisco ASA 5520 Adaptive Security Appliance

The Cisco ASA 5520 Adaptive Security Appliance delivers security services with Active/Active high availability and Gigabit Ethernet connectivity for medium-sized enterprise networks in a modular, high-performance appliance. With four Gigabit Ethernet interfaces and support for up to 100 VLANs, businesses can easily deploy the Cisco ASA 5520 into multiple zones within their network. The Cisco ASA 5520 Adaptive Security Appliance scales with businesses as their network security requirements grow, delivering solid investment protection.
Businesses can extend their SSL and IPsec VPN capacity to support a larger number of mobile workers, remote sites, and business partners. Up to 750 AnyConnect and/or clientless VPN peers can be supported on each Cisco ASA 5520 by installing an Essential or a Premium AnyConnect VPN license; 750 IPsec VPN peers are supported on the base platform. VPN capacity and resiliency can be increased by taking advantage of the Cisco ASA 5520's integrated VPN clustering and load-balancing capabilities. The Cisco ASA 5520 supports up to 10 appliances in a cluster, offering a maximum of 7500 AnyConnect and/or clientless VPN peers or 7500 IPsec VPN peers per cluster. For business continuity and event planning, the Cisco ASA 5520 can also benefit from the Cisco VPN FLEX licenses, which enable administrators to react to or plan for short-term bursts of concurrent Premium VPN remote-access users, for up to a 2-month period.
The advanced application-layer security and content security defenses provided by the Cisco ASA 5520 can be extended by deploying the high-performance intrusion prevention and worm mitigation capabilities of the AIP SSM, or the comprehensive malware protection of the CSC SSM. Using the optional security context capabilities of the Cisco ASA 5520 Adaptive Security Appliance, businesses can deploy up to 20 virtual firewalls within an appliance to enable compartmentalized control of security policies on a departmental level. This virtualization strengthens security and reduces overall management and support costs while consolidating multiple security devices into a single appliance.

 Cisco ASA 5520 Adaptive Security Appliance Platform Capabilities and Capacities

Feature

Description

Firewall Throughput

Up to 450 Mbps

Maximum Firewall and IPS Throughput

• Up to 225 Mbps with AIP SSM-10
• Up to 375 Mbps with AIP SSM-20
• Up to 450 Mbps with AIP SSM-40

VPN Throughput

Up to 225 Mbps

Concurrent Sessions

280,000

IPsec VPN Peers

750

Premium AnyConnect VPN Peer License Levels1

2,10, 25, 50, 100, 250, 500, or 750

Security Contexts*

Up to 20

Interfaces

4 Gigabit Ethernet ports and 1 Fast Ethernet port

Virtual Interfaces (VLANs)

150

Scalability

VPN clustering and load balancing

High Availability

Active/Active2, Active/Standby

1Separately licensed feature; includes two with base system
2Available for the firewall feature set
