Digital Hydrualic Cement Mortar Testing Machine for manufacture
- 50 Set / Sets per Month
- Shanghai Port or other port in china
- T/T Credit Card
Product Details
Place of Origin: | Shanghai, China | Brand Name: | SX | Model Number: | SX-300 |
Power: | Hydraulic | Usage: | Other, Compression Testing Machine, do compression and flexure test |
Product Description
Product Name : Digital Hydrualic Cement and Mortar Testing Machine
Functional use :
the Eletro-Hydraulic Pressure Testing Machine is mainly used for Compression strength test of cement and mortar,
Suitable to compression test in construction material with below 300kn strength material like concrete, tile .
This machine adopts hydraulic loading, electronic measuring, with load figures show that loading rates show that the maximum load to maintain, as well as overload protection, and power data retention and other functions.
Specificatios:
Maximum test force : 300kN (compressive)
Testing force rang : 4% - 100% FS
Relative error: ≤ ± 1% Hydraulic Pump Rated Pressure: 25MPa
Loading speed : 0.3Kn/s-10Kn /s
Rative error of loading speed: ± 5%
Bearing plates size: φ155mm
Test space between up and down bearing plate : 230mm Piston diameter and Max stroke φ130mm × 80mm Motor power : 3 phase 0.75 kW
Packing information:
Plywood case packing material Dimensions : 850 × 300 × 1300mm (L × W × H)
Net weight : about 400Kg
Package No: 1
