Specifications
1. Strong mechanical properties;2. Excellent corrosion resistance;
3. High and homogeneous heat diffusion.
In detail:
Features:
1.Superior quality of raw material;
2.Reasonable and stable chemical composition.;
3.Accurate tolerance;
4.Good mechanical property.;
5.We have the certificate of ISO9001:2008.;
6.We provide free sample service.
7.The products can be made according to your requirement.
TOLERANCE | |||||
Major Brand |
A1100(O) A1050(O) |
||||
Thickness |
0.2-0.4 |
0.4-0.8 |
0.9-1.1 |
1.2-1.6 |
1.8-2.0 |
tolerance |
±0.01 |
±0.015 |
±0.02 |
±0.025 |
±0.03 |
Width |
<100 |
100-200 |
201-500 |
501-1250 |
>1250 |
tolerance |
±0.1 |
±0.2 |
±0.2 |
±1 |
±2 |
BURR AND COLLAPSE | |||||
The width of aluminum belt |
burr’s height |
collapsed side’s height |
|||
<0.2 |
0.01 |
≥0.05-0.1 |
|||
0.2-1.0 |
0.015 |
||||
1.1-1.5 |
0.02 |
||||
>1.6 |
0.03 |
||||
MECHANICAL PROPERTY | |||||
U.T.S: 60-95N/mm2 |
Elongation: >25% |
||||
Density in 20°C :2.703kg/dm3 |
Max.resistance in 20°C:≤0.02825Ωmm2/m |
||||
Aluminium strip |
|
|||||
Alloy |
Thickness(mm) |
Width(mm) |
Temper |
DC or CC |
||
5083 |
0.15-2.0 |
300-1500 |
O,H12,H22,H14,H24,H16,H26,H18,H32 |
DC, CC |
||
2.0-350 |
900-2200 |
H112,H111 |
DC |
|||
|
||||||
Package |
Export standard wooden pallets package |
|
||||
Application |
Electric conductor, flexible hose,Instrument, storage, PS plate, heat Exchanger; Instruction Decoration Material,pressure tank,Roof Panel,sanitary fixture. |
|||||
MOQ |
5MT |
|||||
Attention |
Specifications can be customized as the customer’s requirements. |
|||||
