Color Coated Aluminum Coil 1060

Name: Color Coated Aluminum Coil 1060
Brand: winow
SKU: 126697617
Availability: InStock

Negotiable MOQ: 5 Metric Tons (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Henan, China

Brand Name:

winow

Model Number:

1060

Henan Winow Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name winow

Model Number 1060

Application building decoration or aluminum shutter

Thickness 0.125----1.5mm

Width Under 2200mm

Alloy Or Not Is Alloy

Grade 1000 Series

Surface Treatment Coated

Temper O - H112

Specifications

1. High precision of demensional tolerance;
2. Excelent mechanical property suh as the yield strength and tensile strength.

1.Aluminum shutter

2.Color Coated Aluminum Coil, painted aluminum coil, colored aluminum sheets

Color Coated Aluminum Coil & Sheet
Thickness	Width	PVDF Thickness	Color standard	Pencil hardness
0.18-1.5mm	580mm----1850mm	>25um	E < 2 or it is not obvious by eyeballing	> 2HB
Technical data	1, Coating adhesive: not lower than first grade Impact: no any crack (50kg/cm, ASTMD-2794:1993) 2, Bend strength: >100 times 3, Boiling point: no any distortion and color change (in the 99 more or less 1 degree water, then cooling 2 hours) 4, Corrosive: surface deep in the 5% muriatic acid and 5% NaCL, interior deep in the 2% muriatic acid and 2% NaCL, after 48 hours, no change 5, Pre-treatment material from HenKel &Chemtell from Germany, 6, Paint: 70% PVDF from PPG or Valspar 7, Colors: Can do as your requirement We are the first one to pass CTC of national testing certification center of building materials.
