agricultural frame power sprayer(FP-808B)

Specifications

pact& strong structure
2.full frame to convenient to move and shipping
rrosion-resistant and wear-resisting ceramic



  This agricultural frame power sprayer has below advatanges:



1. Frame structure to convenient to carry to different place to working and for long distance shipping

2. Scientific design of simple and strong structure ,high pressure,big flow rate,long range to meet different spray demands

3. Corrosion-resistant and wear-resisting ceramic painted plunger and viton o-ring and washer pump for long-term use

4.Mating powerful,low consume,environmental protection motor

5. Professional manufacturer of the better quality and service



Application:

Usually for:city garden,forest,plant protection, chemical weed control,exoroot fertilization ,insect&pest control,livestock breeding disinfection,health&antiepidemic,spray,wash,etc.





Parameter:

Model	FP-808B	FP-F-22A	FP-A/B-22/30	FP-C-22A2/30	FP-D-22A2	FP-E-80	FP-E-120
Mating Power(hp)	TU-26/1E34F(0.75)	168F(1.5-2.0)	168F(3.0-5.0)	168F(2.0)	168F(1.5-2.0)	188F(5.0-7.5)	188F(13.0)
Rotational Speed(R.P.M)	5500	800-1200	800-1000	800-1200	800-1000	800-1000	800-1000
Spray Flow Rate(L/min)	8	14-22	14-23/33-40	14-22	14-22	58-68	103-116
Pressure(mpa)	1.5-3.5	2.0-3.5	2.0-3.5	2.0-3.5	2.0-3.5	3.0-5.0	4.0-6.0
Spray Range(m)	5-10	12-16	12-16/15-18	12-16	12-16	15-18	20-25
Hose Length(m)	30	30	30/50	50	50	50	50
Net Weight(kg)	9.5	25	30/33.5	35	35	56	72
Size(cm)	31×31×33	80×35×44	90×35×48	75×43×44	70×37×43	115×41×45	115×41×57
