Specifications
Straightener1.High flattening precise straightener
2.High efficiency Competitive price strightening line
3.Applied to CRS
The technical parameters of 5-16mm china hot rolled steel coil flattening machine:
a. applied to : carbon cold rolled coils
b. material quality : first class steel coils of the international standard
c. tensile strength:δb≤550Mpa
d. thickness:5-16mm
e. width :2000(Max)
f. diameter of leveling rollers:φ200
g. distance of leveling rollers:210mm
h. material of leveling roller:42CrMo, hardness:HRC52-60
The brief intrducion of 5-16mm china hot rolled steel coil flattening machine:
5-16mm china hot rolled steel coil flattening machine
1.It makes uneven steels even and guide them to the right following process. It also do the fixed length cutting and fixed quantity packing to the plates.
2.It is composed of 13 working rollers, driving device,including 2 pinch rollers and machine frame. Both sides of each rolling wheel is transmitted by roll bearing , except the code rollers, all are the main force rollers.
3.The working rollers use 4.4kw electric machine to adjust the upper and lower gap through the turbine decelerator box to make sure the even quality.
4.Drive model: all the independent rollers and gear box are driven by 80Kw DC electromotor and decelerate by decelerator . And it is composed of the gear distributor and all-round coupling as well as the hydraulic brake devices and so on.
Pictures shows of 5-16mm china hot rolled steel coil flattening machine:
Company Information:
Wuxi Bangzhou Machinery Manufacturing Co., Ltd. is located in Changjing Industrial Park, Jiangyin, Wuxi with beautiful environment and very convenient transportation. We are one of the most professional machinery manufacturers in China, integrating design, production, sale and after-sales services.
Our main products are Steel coil slitting lines, cut to length lines, Straightening machines, Automatic crosscut units and Hydraulic shearing machines. Our products are supplied to cold rolling and pipe welding factories
We welcome all friends to visit us. We are sincerely looking forward to receive your guidance and business cooperation!
