1.3megapixel cmos 720p(hd) real dahua poe water-proof hd network small ir-bullet camera ipc-hfw4100s

FOB Price

USD $60 - $60 / Piece

1 Piece(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port SZ
Payment Terms:Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Zhejiang, China	Type:	IP Camera	Style:	Bullet Camera
Sensor:	CMOS	Technology:	Infrared	Special Features:	Waterproof / Weatherproof

Product Description

Feature

• 1/3” 1.3Megapixel progressive scan Aptina CMOS
• H.264&MJPEG dual-stream encoding
• 25/30fps1.3M(1280×960)&25/30fps720P(1280×720)
• DWDR, Day/Night(ICR), 3DNR,AWB,AGC,BLC
• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
• 6mm fixed lens (3.6mm,8mm optional)
• Max. IR LEDs Length 30m
• IP66, PoE

Overview

Specifications

Model	DH-IPC-HFW4100SP	DH-IPC-HFW4100SN
Camera
Image Sensor	1/3” 1.3Megapixel Aptina CMOS
Effective Pixels	1280(H) ´ 960(V)
Scanning System	Progressive
Electronic Shutter Speed	Auto/Manual, 1/3~1/10000s	Auto/Manual, 1/4~1/10000s
Min. Illumination	0.01Lux/F1.2 (Color), 0.005Lux/F1.2(B/W);0Lux/F1.2(IR on)
S/N Ratio	>50dB
Video Output	N/A
Camera Features
Max. IR LEDs Length	30m
Day/Night	Auto(ICR)/Color/B/W
Backlight Compensation	BLC / HLC / DWDR
White Balance	Auto/Manual
Gain Control	Auto/Manual
Noise Reduction	3D
Privacy Masking	Up to 4 areas
Lens
Focal Length	6mm (3.6mm,8mm)
Max Aperture	F1.6
Focus Control	Manual
Angle of View	H: 64.5°(90°/49°)
Lens Type	Fixed lens
Mount Type	Board-in Type
Video
Compression	H.264/ MJPEG
Resolution	1.3M(1280x960)/720P(1280×720)/D1(704×576)/CIF(352×288)	1.3M(1280x960)/720P(1280×720)/D1(704×480)/ CIF(352×240)
Frame Rate	1.3M/720P(1 ~ 25/30fps)(Main Stream)
	D1/CIF(1 ~ 25/30fps)(Sub Stream)
Bit Rate	H.264: 32K ~ 8192Kbps
Audio
Compression	N/A
Interface	N/A
Network
Ethernet	RJ-45 (10/100Base-T)
Wi-Fi	N/A
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour,
ONVIF	ONVIF Profile S
Max. User Access	20 users
Smart Phone	iPhone, iPad, Android, Windows Phone
Auxiliary Interface
Memory Slot	N/A
RS485	N/A
Alarm	N/A
PIR Sensor Range	N/A
General
Power Supply	DC12V, PoE (802.3af)
Power Consumption	<5W
Working Environment	-20°C~+60°C, Less than 95% RH
Ingress Protection	IP66
Vandal Resistance	N/A
Dimensions	70mm×66mm×160mm
Weight	0.5kg
