Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > IPC-HDBW4100E Dahua Full hd Vandal-proof 1.3Megapixel Mini Dome Dahua ir Viewerframe Mode Network ip Camera

IPC-HDBW4100E Dahua Full hd Vandal-proof 1.3Megapixel Mini Dome Dahua ir Viewerframe Mode Network ip Camera

US$ 71.6 - 71.6 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Type:

IP Camera

Style:

Dome Camera

Contact Supplier Request Quote Chat Now

Shenzhen Obdo Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Type IP Camera

Style Dome Camera

Sensor CMOS

Technology Infrared

Special Features Vandal-proof

Product Description

Feature

>1/3” 1.3Megapixel progressive scan Aptina CMOS
> H.264 & MJPEG dual-stream encoding
> 25/30fps1.3M(1280×960)&720(1280×720)
> DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 3.6mm fixed lens (2.8mm, 6mm optional)
> Max. IR LEDs length 30m
> IK10, IP66, PoE

Overview

Specifications

Model	IPC-HDBW4100E
Camera
Image Sensor	1/3” 1.3Megapixel Aptina CMOS
Effective Pixels	1280(H)x960(V)
Scanning System	Progressive
Electronic Shutter Speed	Auto/Manual, 1/3(4)~1/10000s
Min. Illumination	Color: 0.01Lux/F1.2, 0Lux/F1.2(IR on)
S/N Ratio	More than 50dB
Video Output	N/A
Camera Features
Max. IR LEDs Length	30m
Day/Night	Auto(ICR)/Color/B/W
Backlight Compensation	BLC / HLC / DWDR
White Balance	Auto/Manual
Gain Control	Auto/Manual
Noise Reduction	3D
Privacy Masking	Up to 4 areas
Lens
Focal Length	3.6mm (2.8mm, 6mm optional)
Max Aperture	F1.8 (F2.0/F1.8)
Angle of View	H: 70°/89°/46.5°
Lens Type	Fixed lens
Mount Type	Board-in Type
Video
Compression	H.264 / MJPEG
Resolution	1.3M(1280×960) / 720P(1280×720) / D1(704×576/704×480) /CIF(352×288/352×240)
Frame Rate	1.3M/720P(1 ~ 25/30fps) (main stream)
Frame Rate	D1/CIF(1 ~ 25/30fps) (sub stream)
Bit Rate	H.264: 32K ~ 8192Kbps
Audio
Compression	N/A
Interface	N/A
Network
Ethernet	RJ-45 (10/100Base-T)
Protocol	IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
ONVIF	ONVIF Profile S
Max. User Access	20 users
Smart Phone	iPhone, iPad, Android, Windows Phone
Auxiliary Interface
Memory Slot	N/A
RS485	N/A
Alarm	1/1 channel In/Out (optional)
PIR Sensor Range	N/A
General
Power Supply	DC12V, PoE(802.3af)
Power Consumption	Max 3.5W
Working Environment	-20°C~+60°C, Less than 95% RH
Ingress Protection	IP66
Vandal proof	IK10
Dimensions	Φ110mm x 81mm
Weight	0.29Kg
