Low Price With High Quality Parker Solenoid Valve

Name: Low Price With High Quality Parker Solenoid Valve
Brand: BELL
SKU: 126579655
Availability: InStock

US$ 50 - 500 MOQ: 1 Set

Key Specifications

Standard or Nonstandard:

Standard

Structure:

Control

Pressure:

Medium Pressure

Tianjin Bell Automatic Instrument Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Standard or Nonstandard Standard

Structure Control

Pressure Medium Pressure

Power Solenoid

Material Casting

Temperature of Media Medium Temperature

Media Gas

Port Size 1/2''--12''

Place of Origin Tianjin, China

Model Number RQDF

Brand Name BELL

Specifications

1. parker solenoid valve
2. for natural gas, purity coking gas
3. with advanced technology
4. swift delivery
5. ISO, CE, AAA

Low price with high quality parker solenoid valve

Introduction:

The solenoid valve especially designed for gas manufactured by our company is widely

used in almost every field of gas industry, such as the automatic cut-off and remote

control of city gas, coking gas, natural gas pipelines, gas boiler safety protection,

furnace heating, etc automatic control system.

Features:

Adopt unique streamlined spherical body, small flow resistance, pressure loss is small.
Coil adopts compound high-quality enameled wire, good insulation effect, low temperature rise.
With corrosion resistant high permeability core material, aerodynamic torque, fast speed, no magnetic remnant phenomenon.
Diaphragm adopts excellent corrosion resistance of nitrile butadiene rubber or fluorine rubber, outer lining protection ring set, can effectively extend the service of the product.
Built-in energy-saving control coil cooling module, it can reduce the coil temperature rise and save energy.

Technical Parameters:

Working medium: natural gas, city gas, liquefied petroleum gas, purity coking gas
Connection method: <=DN50 inch pipe thread or flang; >=DN65 standard flange
Medium temperature: diaphragm type: <=80C piston type: <=80C
Environment temperature: -20C~40C
Supply voltage: 220VAC/DC 24VAC/DC ( special voltage can be customed )
Optional function: contact feedback, manual operation, explosion-proof type
Explosion level: ExIICT4 ( IIC only include H2 )
Protection class: IP65
