Flanged Concentric Control Butterfly Valve
US$ 50 - 5,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Butterfly
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Manual-operated Wafer Butterfly Valve Quickly DeliveryUS$ 100 - 2,000MOQ: 1 Set -
Hand Lever Wafer Butterfly ValveUS$ 50 - 1,000MOQ: 1 Set
-
Manual-operated Wafer Control Butterfly ValveUS$ 50 - 2,000MOQ: 1 Set
-
Cast Steel Manual-operated Flanged Concentric Butterfly ValveUS$ 50 - 2,000MOQ: 1 Set
-
Cast Steel Manual-operated Flanged Concentric Butterfly Valve ManufacturersUS$ 50 - 500MOQ: 1 Set
Standard or Nonstandard
Standard
Structure
Butterfly
Pressure
Medium Pressure
Power
Manual
Material
Stainless Steel
Temperature of Media
Normal Temperature
Media
Acid
Port Size
2"--40"
Place of Origin
Tianjin, China
Model Number
D341X-10,D341X-16
Brand Name
BELL
Specifications
1.Size:2"--40"2.Flange connections, used in the end of pipe.
3.Flanged Concentric Control Butterfly Valve
Flanged Concentric Control Butterfly Valve
Type:D341X-10 D341X-16
Nominal Diameter |
50(2”)—300(12”)mm |
Nominal pressure: |
1.0 MPa 1.6MPa |
Operating Temperature Range |
-15~150 Degrees Celsius |
Suitable Mediums |
Fresh water,sewage,air,ect |
Features:
1)Rubber vulcanized into inner valve body, without any leakage in the connecting point
2)Hard rubber liner without movement, high reliability, more than ten thousand times of rotation operating experiment(circle),longer operating life
3)Reasonable rubber and valve seal design, small torque, high sealing pressure, tight junction free of bubbles.
4)Flange connections, used in the end of pipe.Demount up or low part of pipe during maintenance at will
