JB/T9092 Tested Pneumatic Butterfly Valve Adopted to Alkali

JB/T9092 Tested Pneumatic Butterfly Valve Adopted to Alkali thumbnail-1
JB/T9092 Tested Pneumatic Butterfly Valve Adopted to Alkali photo-1
US$ 50 - 200 MOQ: 1 Set
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Butterfly
Pressure:
Other, 0.6,1.0MPa,150lb,etc
Contact Supplier Request Quote Chat Now
Tianjin Bell Automatic Instrument Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin xingang port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard or Nonstandard Standard
Structure Butterfly
Pressure Other, 0.6,1.0MPa,150lb,etc
Power Pneumatic
Material Other, Carbon Steel,Stainless Steel,Cast Iron,etc
Temperature of Media Other, -40℃~160℃ based on seal material
Media Other, Water, salt, acid, alkali, nature gas, air, alcohols, oils, etc
Port Size DN50-800(2"~32")
Place of Origin Tianjin, China
Model Number BGTWA
Brand Name BELL
Application General

JB/T9092 tested Pneumatic butterfly valve adopted to alkali



Product Description

Pneumatic Butterfly Valve Technical Parameters:



1.Pneumatic butterfly valve can be equipped with pneumatic actuator which controlled by solenoid valve, can be used as a cut-off  pneumatic butterfly valve, with pneumatic actuators which has positioner can be used

as a regulated type pneumatic butterfly valve.

2.According to user requirements, the pneumatic butterfly valve with pneumatic actuator can be equipped with positioners, air filter reduce pressure regulator, limit switch, hand wheel, solenoid valve.

3.BGTWA Series  middle-line wafer type pneumatic butterfly valve,using BGT series pneumatic actuator

4.BAWWA Series pneumatic wafer middle-line butterfly valve,using BAW series pneumatic actuator.

5.The pneumatic control butterfly valve has small size, light weight, reasonable structure, easy installation,

and is suitable for high-volume low-pressure fluid control and regulation of solid powder, closure and so on.





Pneumatic Wafer Butterfly Valve Reference Standard:



Nominal Diameter

DN(mm)

40~1000

50~600

NPS(inch)

1.5”~40”

2”~24”

Nominal Pressure  PN(MPa)

1.0

1.6

Test Pressure

MPa

Seal

1.1

1.76

Shell

1.5

2.4

Applicable temperature ℃

-15~+150

Applicable medium

Fresh water, sewage, sea water, air, steam, food, medicine,

Oils, acids, bases, salts





Pneumatic Wafer Butterfly Valve Main Parts Material:



Body

Disc

Shaft

Rubber Seat

Bushing

Material Name

Code

Material Name

Code

Material

Name

Material

Code

Applicable

Temperature℃

Material

Name

Gray cast iron

Z

Plating Ductile

iron

B1

Stainless

Steel

NR

X1

-20~+85

Lubricating

bronze

Ductile Iron

Q

Aluminum

bronze

B2

Carbon

Steel

Hypalon

X2

-18~+135

PTFE

Aluminum bronze

T

Stainless Steel

B3



EPR

X3

-45~+135



ZG1Cr18Ni9Ti

Stainless Steel

P

Titanium steel

B4



Neoprene

X4

-7~+93



CF8M

Stainless Steel

R

CF8M

Stainless Steel

B5



NBR

X5

-12~+82



Carbon Steel

C

Carbon Steel

B6



Wear rubber

X6

-10~+50







CF8

Stainless Steel

B7



Vition

X7

-23~+150













Resistant

EPDM

X9

-20~+150













PTFE

F4

+10~+150





Main picture





JB/T9092 tested Pneumatic butterfly valve adopted to alkali



JB/T9092 tested Pneumatic butterfly valve adopted to alkali



Outline Dimensions

 JB/T9092 tested Pneumatic butterfly valve adopted to alkaliJB/T9092 tested Pneumatic butterfly valve adopted to alkali

Company Information



 JB/T9092 tested Pneumatic butterfly valve adopted to alkaliJB/T9092 tested Pneumatic butterfly valve adopted to alkali





Production Process



JB/T9092 tested Pneumatic butterfly valve adopted to alkali

JB/T9092 tested Pneumatic butterfly valve adopted to alkali



Test&Certifications



JB/T9092 tested Pneumatic butterfly valve adopted to alkali



JB/T9092 tested Pneumatic butterfly valve adopted to alkali



CE security certificate awarded by EU appointed Britain certificate authority

The ISO9001 quality certification

China famous brand certificate

China AAA level credit enterprise certificate

Tianjin Enterprises Association Member

China quality assurance certificate

The Qualified Supplier Certificate Issued by Beijing Capital Iron & Steel Group



Packaging & Shipping



JB/T9092 tested Pneumatic butterfly valve adopted to alkali

FAQ



1. How about your price?

Although we are brand-name products,  but our prices are very favorable and competitive.

Customer from all over the world to purchase our products, because our best price.



 2. How long is your warranty ?

   Our Warranty is 12 month



 3. What’s your payment?

Our Payment could be

(1) 100% T/T

(2) 30% in advance, others before shipment.

(3)Advance, others letter of credit.



 4. What’s your beneficiary bank?

Our beneficiary bank have :

(1)Alibaba one touch account

(2) Alibaba Trade Assurance account

(3) Bell Group's bank account

(4)Tianjin Bell company bank account

(5)Paypal

(6)Western Union

(7) China's domestic use RMB remittance

Specific accounts can be found on our website.



 5. Could you special design and produce for you?

  Sure, we have all kinds of professional engineers,

  Could design and produce special product according to customer requested.

  Such as: special Size, special control, or OEM, etc.



 6. Do you looking for Agent ?

   Yes, we're looking for the agent all over the world, please contact us for further discussion.
