Solar Inverter150w-3kw 12/24v/48v

Solar Inverter150w-3kw 12/24v/48v thumbnail-1
Solar Inverter150w-3kw 12/24v/48v photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
LQ
Model Number:
YP600S48
Contact Supplier Request Quote Chat Now
Jinan Linquan Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name LQ
Model Number YP600S48
Output Power 500 - 1000W
Output Type Single
Size 295(L)*180(W)*72(H)mm
Weight 2.7kgs
Input Voltage 12/24/48
Output Voltage 110/220
Type DC/AC Inverters
Output Frequency 50/60
Output Current <2A

Specifications

1:Car Power Inverter
2:exported to NorthAmerica,Europe,Indonesia,Australia,Japan,Korea and so on
3:Certification:CE

solar inverter is detailed as follow :



power inverter:

S600 inverter provides 600 continuous watts of pure sine wave output from your DC battery. Designed for operating entertainment electronic and sensitivity loads, S600 featuS solid-state circuitry precisely regulates the voltage and frequency of the pure sine wave output and auto low voltage shut down protects your expensive batteries from excessive depletion.

1. Pure sine wave output(THD<4%)
2. High efficiency 88~94%
3. Capable of driving inductive & capacitive loads

4. Tri-Color indicators display input/ output voltage, load level and failure status

5. High surge capable of starting motor load

6. Loading controlled cooling fan Advanced microprocessor

7. SC/OV/UV/OT/OL protections

ModeModel

S600-
112

S600-
124

S600-
148

S600-
212

S600-
224

S600-
248

0Output Power

600W

Output Power(Max)

680W

Surge Power

800W

Input Voltage

12VDC

24VDC

48VDC

12VDC

24VDC

48VDC

Output Voltage

100/110/120VAC+-3%

220/230/240VAC+-3%

Frequency

50/60HZ+/-0.05%

Efficiency(Full Load)

87%

90%

92%

90%

93%

94%

Output Current

0.87A

0.43A

0.23A

0.83A

0.43A

0.22A

Output Wave

Pure sine wave(THD<3%)

Output Voltage Range

100/110/120Vrms-10%+4%

220/230/240Vrms-10%+4%

Input Voltage Range

10.5-15

21.0-30

42.0-60

10.5-15

21.0-30

42.0-60

LED display Voltage&Load

LED Red/Orange/Green

Automatic Protection

overload,short circuit,over/under input voltage,reverse polarity(fuse)

Safety

UL458

EN60950

EMC

FCC Class B

EN50081-1:1992

e-Mark
e13-020866

EN50082-1:1992

EN55022B:1994

EN61000-4-2:1995

EN61000-4-3:1996

ENV50204:1995

Operating Tem.

0  ~50 degree

Storage Temperature

-30  to70 degree

Cooling

Automatically controlled cooling fan

Dimensions

295(L)*180(W)*72(H)mm /11.61(L)*7.09(W)*2.83(H)inch

Weight

2.7kgs./5.4Lbs.
