1KW Output Short Circuit Protection,Full Automatic Intelligent Switch Intelligent Inverter

Jinan Linquan Import And Export Co., Ltd.
1KW Output Short Circuit Protection,Full Automatic Intelligent Switch Intelligent Inverter thumbnail-1
1KW Output Short Circuit Protection,Full Automatic Intelligent Switch Intelligent Inverter photo-1
US$ 180 - 197 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
LQTRADE
Model Number:
LQYTP-1KW-I
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name LQTRADE
Model Number LQYTP-1KW-I
Output Power 500 - 1000W
Output Type Single
Size 388*145*210
Weight 9KG
Input Voltage 24V/48V
Output Voltage 110-230V
Type DC/AC Inverters
Output Frequency 50/60HZ
Output Current 15

Specifications

1KW Output short circuit protection,Full automatic intelligent switch Intelligent Inverter
Exported to North America,Europe etc

1KW Output short circuit protection,Full automatic intelligent switch Intelligent Inverter

 Introduction:

The output voltage wave form for this inverter is pure sine wave and with isolated transformer.

Not only for homeuse loads like fans, fluorescent lights, audio amplifiers, TV, Game consoles, Fax, and answering machines.Especial loads like air condition and Motor.



Performance Specification of Intelligent Inverter

The inverter is designed by our company independently;it’s CPU controlled,high quality,low cost and pure sine wave intelligent inverter in the world.

The inverter can be used for loads (including fan,refrigerator,air-condition.water pump electromotor)



Functions:

Full automatic intelligent switch.

Output short circuit protection.When there is short circuit,the inverter will indicate it and lock the machine automatically.

Overload protection .When there is overload ,the machine will prompt you and delay lock machine automatically to protect the inverter from being damaged



1KW Output short circuit protection,Full automatic intelligent switch Intelligent Inverter



Technical parameters:





Input

Rated capacity(W)

1000W

Commercial Power range(VAC)

100/110/120/127/220/230(+25%,-35%)

Frequency(Hz)

60/50±10%

Output

AVR voltage range(VAC)

100/110/120/127/220/230±10%

Transfer time

<9ms

Waveform

Pure sine wave

Frequency

Commercial power supply: shared frequency with the commercial inversion state:60/50±0.5

Protection

overload

Input/output over high or low protecting; low battery protecting; surge and pike-currents protecting; overload protecting 100%-120% 30sec; >120% 100ms; >150%, 50ms output short circuit <150ms

Battery

DC Voltage

24/48VDC

TYPE

Sealed, maintenance-free lead acid

Recharge current

15A(Maximum)

Battery protection

Automatic self-test, discharge protection, over-charging protected, smart management system.
