Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Controller > LQ-1000W Pure Sine Wave Solar Power Inverter 48V DC Input, 110V/220V AC Output, With USB Model No.: YP1000S48

LQ-1000W Pure Sine Wave Solar Power Inverter 48V DC Input, 110V/220V AC Output, With USB Model No.: YP1000S48

Jinan Linquan Import And Export Co., Ltd.
LQ-1000W Pure Sine Wave Solar Power Inverter 48V DC Input, 110V/220V AC Output, With USB Model No.: YP1000S48 thumbnail-1
LQ-1000W Pure Sine Wave Solar Power Inverter 48V DC Input, 110V/220V AC Output, With USB Model No.: YP1000S48 photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
LQtrade
Model Number:
YP1000S48
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name LQtrade
Model Number YP1000S48
Application Other, Solar Power Inverter
Rated Voltage Other, 12V/24V

Specifications

Features:
Dedicated design for the use of Solar Power Energy
Pure Sine Wave
Wireless Remote Control and Wired Remote Control

1000W Pure Sine Wave Solar Power Inverter 48V DC Input, 110V/220V AC Output, with USB Model No.: YP1000S48

Products Description:
Continue Power: 1000 W
Max. Output Surge: 2000 W
DC Input Voltage: 12V or 24V or 36v or 48V
AC Output Voltage: 100V / 110V / 115V / 120V / 200V/ 220V / 230V / 240V be selected
Dimensions (mm): 320 x 157 x 75
Weight:2.7kg

Features:
Dedicated design for the use of Solar Power Energy
Pure Sine Wave
Wireless Remote Control and Wired Remote Control (Optional)
Supply USB 5V/500mA
High temperature alarm and protection system
Output overloaded alarm and protection system
Output short circuit alarm and protection system
High surge capacity for starting demanding loads
Alarm and protection for low / high battery

Scope of Application:
Medical Instruments, Emergency Power, Oxygen Concentrators, Cash Register, Home Theater, High-end Stereos, Notebook,
Computers, Power Tools, Radios, DVD players, TV's , Musical Instruments, Recording Equipments, Limousines, Buses, RV's,
Precision Equipment, Sensitive Radio Equipment, Laser Printers, Fax Machines, etc.
USB 5V DC output is for Digital Camera, Cell Phone, Video Game, MP3, MP4, PDA.

ModelYP-1000S12YP-1000S24YP-1000S48
OutputContinuous output1000W
Surge Power2000W
AC Voltage100V / 110V / 115V / 120V / 200V/ 220V / 230V / 240V to be selected
RegulationVrms  3%
Frequency50Hz or 60Hz
Wave FormPure Sine Wave
Total Harmonic DistortionTHD <3%
USB OutputDC 5V 5% 500mA
InputBattery Voltage12V24V48V
DC Current (typ.)100A50A25A
Low Battery Alarm10.5V 2%21V  2%42V  2%
Battery Voltage Low Stop10V  2%20V  2%40V 2%
High Battery15V 2%30V 2%60V  2%
No load current900mA500mA230mA
Efficiency>90%
ProtectionHigh temperatureYes
Short-circuitYes
OverloadYes
Input VoltageYes
Intelligent Design Heat Auto ControlFan Start : 42C  3 , Fan Stop : 38C 3
High Temperature Shut Down : 63C  3 , Restart Output : 55C 3
IndicatorNormally : Green LED   Over Temperature : Yellow LED  Exceptionally : Red LED
OthersOptional with wireless remote control or without remote control
MechanicalDimensions (mm)320 (D) x 157 (W) x 75 (H)
Weight2.7 kgs



LQ-1000W Pure Sine Wave Solar Power Inverter 48V DC Input, 110V/220V AC Output, with USB Model No.: YP1000S48LQ-1000W Pure Sine Wave Solar Power Inverter 48V DC Input, 110V/220V AC Output, with USB Model No.: YP1000S48LQ-1000W Pure Sine Wave Solar Power Inverter 48V DC Input, 110V/220V AC Output, with USB Model No.: YP1000S48LQ-1000W Pure Sine Wave Solar Power Inverter 48V DC Input, 110V/220V AC Output, with USB Model No.: YP1000S48LQ-1000W Pure Sine Wave Solar Power Inverter 48V DC Input, 110V/220V AC Output, with USB Model No.: YP1000S48
