Specifications
1.Light weight2.Fireproof and thermal insulation
3.Easy to install
Specifications
1. Sandwich board
2. Core material: Foam (EPS/ PU /Rock wool)
3. Sound insulation, heat insulation boards
Color steel foam sandwich panel / EPS sandwich panel / PU sandwich panel / rockwool sandwich panel.
Advantage:
1.Light in weight: 6-24kg/m3, easy to install(donnot need crane), save more construction period and low the cost.
2. Excelent Sound Insulation, heat insulation, waterproof and damp resistant with it's good appearance.
3. Large load: Used as supporting structure and defense device for it's characteristic of high intension rigidity.
4. Panel length is according to the buyer's request, and the steel color is flexible based on the RAL standard, that makes your building more beautiful.
5. Eco-friendly
Color steel foam sandwich panel / EPS sandwich panel / PU sandwich panel / rockwool sandwich panel. | ||
Type |
color steel foam sandwich panel (overlap joint) |
|
Dimensions |
Total thickness |
50-200mm |
Width |
950/980mm (effective width) |
|
Length |
Less than 11.8m |
|
External face |
Material |
ppgi |
Thickness |
0.17-0.8mm |
|
Thickness of the zinc |
80g/m2 |
|
Corrosion protection |
Galvanized |
|
Coating |
Polyester |
|
Thickness of coating |
20 micron |
|
Color |
According to the RAL |
|
Pattern |
Nearly plain |
|
Insulation |
Optional foam Material |
EPS / PU / Rock wool |
Thickness |
25-300mm |
|
Density |
6-24kg/m3 |
|
Thermal conductivity |
0.02~0.03w/mk |
|
Internal face |
Material |
PPGI |
thickness |
0.18-0.6mm |
|
Thickness of zinc |
80g/m2 |
|
Corrosion protection |
Galvanized |
|
Coating |
Polyester |
|
Thickness of coating |
7micron |
|
Pattern |
Plain |
|
