TY-850 interlock concrete pave stone brick making machines widely usage
- 30 Set / Sets per Month
- qingdao port
- T/T
- China pe200x300 smallest jaw crusher
- Popular compound pendulum jaw crusher price
- 2016 china products stone coated steel roofing tile ,shingle steel roof tile
- 2016 china products lightweight roof tile,blue glazed roof tile
- colored metal roofing prices,sand coated metal roofing tiles
- roofing tiles coated with stones,roofing tiles for houses
Product Details
Condition: | New | Type: | Paving Block Making Machine | Brick Raw Material: | Concrete |
Processing: | Brick Molding Machine | Method: | Hydraulic Pressure | Automatic: | Other, SEMI |
Capacity: | 2000pcs/day | Place of Origin: | Shandong, China | Brand Name: | Tianyuan |
Model Number: | TY-850 | Voltage: | Request | Power: | 9.6KW |
Dimension(L*W*H): | 2.x2x1.8 | Certification: | ISO9001/CE | Warranty: | One Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Size(LXWXH) mm | Pcs/mould | Pcs/hr | Pcs/hr |
350x350x120 | 1 | 200 | 1600 |
200x100x50 | 1 | 440 | 3500 |
The type 850 can produce all kinds of solid bricks and paving bricks,
only by changing different moulds.
B: Technical parameters of 850:
Main machine size | 2.1x2.1x2mm |
| Pallet size | No need |
Main machine power | 8.5kw |
| Weight | 2.7Ton |
Forming cycle | 60seconds |
| Voltage | 380v/3phase |
C: TY-850 machine other information:
1. Area: Workshop area: 30-50m2, all factory area 1000m2, the bigger, the better.
2. Workers : three or four.
3. Ratio of raw material:cement 8%-10% sand 30%-40% stone:50%-60%,about cement :sand : stone is1:4:5.
lid brick weight:
(240*110*53) :3KG
5. raw material consumption per day:10-12T
6. water consumption per day:3%-5% of raw material Weight.
D.TY-850 machine guarantee:
Our hollow block making machine is of one year guarantee,during the period we could supply spare parts if they are broken.
E.TY-850 machine production pressure:
Hollow blocks can reach 8-10Mpa,Solid bricks can reach 10-12Mpa,so they have a high pressure,can be used widely.
*Huarun Tianyuan Factory
1* We are the professional manufacturer of AAC Block Plant& Concrete Brick Block machine & Expanded Perlite Slab Molding Machine & EPS Insert Concrete Hllow Block Machine, & Fireproof door core making machine, with high technology research develop teams, more than 15years experience in this fields, cover 80000sqm and more than 400 staffs.
2* Our products with CE/ISO certification had been sold to more than 106 countries, and well received high acceptance.
3* We had successfully designed the Slope protection brick machines for South-to-North water diversion project, this is the biggest water diversion project in China Government.
4* We had successfully designed EPS(polystyrene) insert concrete hollow block machines. For chinese North-East building company.
5* We had successfully designed thermal insulation Expaned Perlite Slab molding machines for outside wall heat insulation. We are top leader in Chinese markets, share more than 95% markets.
6* We ensure our products quality and best after sales service.
We will do the best with clients' advice and susgestion.
1> Certification of ISO 9001. CE(MD+LVD)
2> We have inspections every year by National Quality Technical Supervise Department.
3> Our Quality Inspection Department make test of each machine before loading.
1: Keep the machine in dry environment.
2: Before the first production, please fill hydraulic oil into the tank, keep the oil level higher than 80/180degree. And pay more attention to the oil Pressure.
3: Please check the Sensor position before each shift, and tighten them again.
4: After each shift, please cleaning all the equipments, and lubricating each running parts.
5: Please cut off the Total Power when User maintaining the machine.
6: When need to change mold, please discharge or install them slowly and keep the Up mold foot safety. Please do it as our video.
7: If need technical help, please call 0086-539-3551999, 24hours online service.
Or please chat by Trade manager: cntianyuanzj
Or Send Email: tianyuanzj at .
WhatsApp: 008615006593716
