Germany technology aac autoclaved aerated concrete blcok production line for sale
1> Certification of ISO 9001. CE(MD+LVD)
2> We have inspections every year by National Quality Technical Supervise Department.
3> Our Quality Inspection Department make test of each machine before loading.
1. Germany technology aac autoclaved aerated concrete blcok production line for sale (tianyuan brand) Planning and design:
Factory covers an area of 6000~30000m2.(workshop at about 1800~3000m2)
Including raw material area, finished block area and production area.
Production flows includes raw material processing, rated material pouring, foaming, cutting and hardening procedure.
From foundation to equipments erection and testing, to trial producing, it will take 4-5months.
2. Germany technology aac autoclaved aerated concrete blcok production line for sale (Tianyuan brand) Material:
1). Coal Flyash or Sand or Quartzite: Dry ash from power plant; sand from river side.
2). Cement: cement in bulk
3). Lime, gypsum and aluminum powder (buy at local area)
4). Water: from fresh AAC production process supply water.
3. Germany technology aac autoclaved aerated concrete blcok production line for sale (Tianyuan brand) Water, electricity and steam supply:
1). Water supply: from well or use waste water
2). Electricity supply: install a 350~500KVA transformer
3). Steam supply: install a 4~8tons boiler to supply steam to autoclave and curing room
4. Germany technology aac autoclaved aerated concrete blcok production line for sale (Tianyuan brand) Product quality and specification :
We produce according to PRC standard GB11968-1997 “Aerated Autoclaved Concrete Block Technology”.
1). Capacity category: 500, 600, 700kgs/ m3 (namely 3.5, 5.0, 7.5 Grade)
2). Compression strength level: 3.5, 5.0, 7.5Mpa (namely 3.5, 5.0, 7.5 Grade)
3). Drying shrinkage: less than 0.8mm/m
4). Thermal system: 0.11-0.22kcal/m.h.c
5). Sound insulation value: 47.45db
6). Frost resistance: 35.
7). Water absorbity :20.
8). Fire resistance: >4h, 200mm thinkness and up >8h.
5. AAC Aerated Autoclaved Concrete plant(Tianyuan brand)Specification
Length: 600mm
Width: 100/ 125/ 150/ 200/ 250/ 300mm
Height: 150/ 200/ 250/ 300mm
6. AAC Aerated Autoclaved Concrete block plant(Tianyuan brand)Main technical parameters
a. Product density should be controlled around 650kgs/m3
b. Annual production capacity: 100,000~300,000 m3
c. Material ratio: cement 5-8%, lime 15-18%, flyash 75%(sand 60-70%), gypsum 4-5%, aluminum powder 500g/m3
d. Water and material ratio: 0.63:1
e. 3.06m3/mould
f. Cutting period: 2-3 minutes
g. Curing time: 1.5-2.5 hours at 45-60°C
h. Autoclave: 6-8 hours(sand 10-12hours)
7. AAC block plant(Tianyuan brand) Main Advantage
1) Light weight
2)Good heat preservation
3)Good fire resistance without releasing harmful gas
4)Good workability
5)Good sound insulation.
7*24hours online service.
@:Designing ,technical support and project;
@Engineer available for overseas installation and adjustment;
@All necessary documents and drawings and videos for free;
@Warranty one year after delivery.
@ 24hours Online service for all life time.
*Huarun Tianyuan Factory
1* We are the professional manufacturer of AAC Block Plant& Concrete Brick Block machine & Expanded Perlite Slab Molding Machine & EPS Insert Concrete Hllow Block Machine, & Fireproof door core making machine, with high technology research develop teams, more than 15years experience in this fields, cover 80000sqm and more than 400 staffs.
2* Our products with CE/ISO certification had been sold to more than 106 countries, and well received high acceptance.
3* We had successfully designed the Slope protection brick machines for South-to-North water diversion project, this is the biggest water diversion project in China Government.
4* We had successfully designed EPS(polystyrene) insert concrete hollow block machines. For chinese North-East building company.
5* We had successfully designed thermal insulation Expaned Perlite Slab molding machines for outside wall heat insulation. We are top leader in Chinese markets, share more than 95% markets.
6* We ensure our products quality and best after sales service.
We will do the best with clients' advice and susgestion.
1: Keep the machine in dry environment.
2: Before the first production, please fill hydraulic oil into the tank, keep the oil level higher than 80/180degree. And pay more attention to the oil Pressure.
3: Please check the Sensor position before each shift, and tighten them again.
4: After each shift, please cleaning all the equipments, and lubricating each running parts.
5: Please cut off the Total Power when User maintaining the machine.
6: When need to change mold, please discharge or install them slowly and keep the Up mold foot safety. Please do it as our video.
7: If need technical help, please call 0086-539-3551999, 24hours online service.
Or please chat by Trade manager: cntianyuanzj
Or Send Email: tianyuanzj at .
WhatsApp: 008615006593716
