Flexible Thin Film Solar Panel/Transparent Solar Panel/PV Module
Flexible Thin Film Solar Panel/Transparent Solar Panel/PV Module
| Quotation for Model (85W A-Si Thin Film Double Glass Solar Module) Specifications | |||||||
| ITEM NO.: | PW85W-TFDG | ||||||
| Maximum Power(W) | 85W | ||||||
| Optimum Power Voltage(Vmp) | 111.85V | ||||||
| Optimum Operatige Current(Imp) | 0.76A | ||||||
| Open Circuit Voltage(Voc) | 144.51V | ||||||
| Short Circuit Current(Isc) | 0.89A | ||||||
| Size of Module(mm) | 1300*1100*8MM | ||||||
| Tolerance (WP) | ±3% | ||||||
| NOCT | 45±3 °C | ||||||
| Power Temp. Coeff(/°C) | -0.27% | ||||||
| Current Temp. Coeff(/°C) | 0.05% | ||||||
| Voltage Temp. Coeff(/°C) | -0.31% | ||||||
| Cell Type | a-Si solar module | ||||||
| Module Efficiency (%) | 7-8% | ||||||
| Transparence (%) | 25% | ||||||
| Warranty | 90% of 10 years,80% of 20 years. | ||||||
| Standard Test Conditions | AM1.5 1000W/square 25 +/-2°C | ||||||
| Weight | 26kgs | ||||||
| Capacity of 20ft container | 25pcs X 16 pallet, 400pcs | ||||||
| Capacity of 40ft container | 25pcs X 32 pallet, 800pcs | ||||||
