Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Cell > 2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v

2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v

2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v thumbnail-1
2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v thumbnail-2
2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v thumbnail-3
2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v thumbnail-4
2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v thumbnail-5
2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v thumbnail-6
2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v photo-1
2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v photo-2
2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v photo-3
2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v photo-4
2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v photo-5
2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v photo-6
US$ 0.37 - 0.5 MOQ: 1000 Watts
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Power World
Model Number:
PW200-72
Contact Supplier Request Quote Chat Now
Qingdao Power World Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Power World
Model Number PW200-72
Material Monocrystalline Silicon
Size 1580X808X35mm
Number of Cells 72
Max. Power 206

2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v



NO. TYPE PW200M-72
1 Peak Power(Pm) 200W
2 efficiency rate 18.0%
3 Power Tolerance ±3%
4 Open circuit Voltatge(VOC) 44.46V
5 Short Circuit Current(ISC) 5.62A
6 Maximum Power Voltage(Vmp) 37.62V
7 Maximum Power Current(Imp) 5.32A
8 Size of Module 1580×808×35mm
9 Cell Type Monocrystalline
10 Quantity and Dimession of   Cell 72pcs,125×125mm
11 Glass type and Thickness Low iron tempered 3.2mm
12 Maximum System Voltage(V) 1000V
13 Temperature coefficiencent Isc (%) +0.04±0.015 % / °C
14 Temperature coefficiencent Voc (%) -(0.35±0.02)% / °C
15 Temperature coefficiencent Pm (%) -(0.5±0.05)% / °C
16 Temperature coefficiencent Im (%) +0.04% / °C
17 Temperature coefficiencent Vm (%) -0.38% / °C
18 Operating temperatures -40°C ~+90 °C
19 Surface pressure 60m/s (200kg /m2)
20 Weight about 16kg





2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v



 2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v

2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v

2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v

2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v

2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v

2016 Best 350W 500W 1KW Mono/Poly Solar Panel Kits 12v



FQA



Q: Are you manufacturer or trading company?

A: We are manufacturer and trader. Both of them.

Q: How many employees in your company?

A: We have about 50~100 employees, including office staff, R & D engineers, production line workers.

Q: Which certificates do you have?

A: We have CE, TUV, IEC, CEC, MCS, UL.

Q: Which countries or regions have you exported to?

A: Aisa like South Korea, Sri Lanka, Thailand, Vietnam, India, Pakistan, UAE, Russia; Europe like Germany, France, Beligum; North America like USA, Mexico; South America like Peru, Chile; Africa like South Africa, Mali, Tunisia and Australia etc.

Q: What is your advantage product?

A: Solar Panel. We have different quality grade solar panel for different markets and customers. OEM & customer customized is welcome.

Q: Does your company also provide other solar products except solar panel?

A: We also supply BIPV, LED, solar pumps and the related solar products.

Q: How can we get some samples to test?

A: Sample order is ok for us. Usually we use DHL, Fedex to you, which is quick but a bit expensive.

Q: How can we get the cheaper price?

A: As long as MOQ is more than 100pcs then we would like to try our best to give you the best price to avoid bargain again and again.

Q: We need C/O. Can you supply?

A: Yes, we have the related experiences to supply C/O, FORM A, FORM F and so on.



Why Choose us



Professional manufactures, strict quality control & full automatic production equipment

Professional salesmans, who have more than 10 years international business experiences

High vonversion efficiency, high transmisson rate, low iron tempered anti-reflecting/coating film 3.2mm glass

Anti-aging & high visosity EVA

High frame resistant & double-sided flourine TPT

Anodized aluminum alloy high thickness frame

3 or 6 bypass diodes, 90mm 4m2 cable, MC4 connectors & waterproof junction box

Long life, easy installation, high wind and hail impact resistance etc advantage

ISO 9001:2008/ISO14001:2004, CE/TUV/CEC/IEC 61215/IEC61730

10 years warranty on workmanship,10 years 90% & 25 years 80% Of The Power Output
