Home > Products > Solar Appliance > High-Lift Solar Water Pumps System
High-Lift Solar Water Pumps System
USD $100 - $880
/ Set
1 Set(Min.Order)
- 10000 Set / Sets per Month
- FOB China
- T/T Credit Card PayPal
You May Like
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Shandong, China | Brand Name: | Power World | Model Number: | PW-SP022 |
Theory: | Centrifugal Pump | Structure: | Screw Pump | Usage: | Water |
Power: | Electric | Standard or Nonstandard: | Standard | Fuel: | Other, Solar Energy |
Pressure: | Low Pressure | Application: | Submersible |
Product Description
Specifications
1.Solar Water Pumps2.High Efficiency
3.High-Lift, No Noise, No Pollution
No. | Model | Voltage | Power | Match solar panel reference | Flow & Lift | Outlet | |||
V/DC | W | Power(W/PCS) | Voltage(V/PC) | m³/h & m | (inch) | ||||
1 | 4PSP2-3 | 36 | 500 | 110W*6 | 14.5 | 1.2m³/h 25m | 2m³/h 22m | 2.4m³/h 18m | 1.25" /1.5" /2" |
2 | 4PSP2-6 | 72 | 700 | 115W*8 | 21.6 | 1.2m³/h 56m | 2m³/h 50m | 2.4m³/h 47m | |
3 | 4PSP2-11 | 110 | 1100 | 120W*12 | 22 | 1.2m³/h 81m | 2m³/h 70m | 2.4m³/h 64m | |
4 | 4PSP2-17 | 150 | 1500 | 120W*16 | 22.5 | 1.2m³/h 128m | 2m³/h 112m | 2.4m³/h 104m | |
5 | 4PSP2-23 | 220 | 2200 | 110W*26 | 20.5 | 1.2m³/h 160m | 2m³/h 140m | 2.4m³/h 127m | |
6 | 4PSP2-26 | 300 | 3000 | 130W*30 | 24 | 1.2m³/h 258m | 2m³/h 222m | 2.4m³/h 203m | |
7 | 4PSP3-16 | 150 | 1500 | 120W*16 | 22.5 | 2.4m³/h 104m | 3m³/h 88m | 3.6m³/h 71m | |
8 | 4PSP3-20 | 220 | 2200 | 110W*26 | 20.5 | 2.4m³/h 37m | 3m³/h 107m | 3.6m³/h 82m | |
9 | 4PSP4-2 | 36 | 500 | 110W*6 | 14.5 | 3.6m³/h 19m | 4m³/h 17m | 4.8m³/h 14m | |
10 | 4PSP4-4 | 72 | 700 | 115W*8 | 21.6 | 3.6m³/h 34m | 4m³/h 32m | 4.8m³/h 26m | |
11 | 4PSP4-8 | 110 | 1100 | 120W*12 | 22 | 3.6m³/h 49m | 4m³/h 46m | 4.8m³/h 37m | |
12 | 4PSP4-12 | 150 | 1500 | 120W*16 | 22.5 | 3.6m³/h 77m | 4m³/h 72m | 4.8m³/h 60m | |
13 | 4PSP4-18 | 220 | 2200 | 110W*26 | 20.5 | 3.6m³/h 106m | 4m³/h 97m | 4.8m³/h 76m | |
14 | 4PSP4-22 | 300 | 3000 | 130W*30 | 24 | 3.6m³/h 120m | 4m³/h 109m | 4.8m³/h 82m | |
15 | 4PSP6-3 | 72 | 700 | 115W*8 | 21.6 | 4.8m³/h 27m | 6m³/h 22m | 7.2m³/h 17m | |
16 | 4PSP6-6 | 110 | 1100 | 120W*12 | 22 | 4.8m³/h 43m | 6m³/h 37m | 7.2m³/h 29m | |
17 | 4PSP6-8 | 150 | 1500 | 120W*16 | 22.5 | 4.8m³/h 59m | 6m³/h 50m | 7.2m³/h 37m | |
18 | 4PSP6-10 | 220 | 2200 | 110W*26 | 20.5 | 4.8m³/h 72m | 6m³/h 62m | 7.2m³/h 44m | |
19 | 4PSP6-14 | 300 | 3000 | 130W*30 | 24 | 4.8m³/h 117m | 6m³/h 103m | 7.2m³/h 83m | |
20 | 4PSP8-4 | 110 | 1100 | 120W*12 | 22 | 7.2m³/h 23m | 8m³/h 21m | 9.6m³/h 17m | |
21 | 4PSP8-6 | 150 | 1500 | 120W*16 | 22.5 | 7.2m³/h 35m | 8m³/h 32m | 9.6m³/h 26m | |
22 | 4PSP8-7 | 220 | 2200 | 110W*26 | 20.5 | 7.2m³/h 43m | 8m³/h 40m | 9.6m³/h 31m | |
23 | 4PSP8-11 | 300 | 3000 | 130W*30 | 24 | 7.2m³/h 72m | 8m³/h 68m | 9.6m³/h 58m |
Solar Water Pumps
