Help CenterDC Type 35W Slim HID Motorcycle Ballast
Related Products
-
AC 25W HID Xenon Bulb H6 Motorcycle BulbNegotiableMOQ: 1000 Pieces -
AC 35W HID Xenon Bulb H6 Hi/lo Motorcycle BulbNegotiableMOQ: 1000 Pieces
-
AC 35W Slim Ballast Motorcycle Conversion KitNegotiableMOQ: 500 Sets
-
Motorcycle Hid KitUS$ 10.5 - 11MOQ: 20 Sets
-
Motorcycle HID KitNegotiableMOQ: 200 Sets
Specifications
DC type 35W slim ballast, input voltage 9V~16V, special for motorcycle, alluminium bodyDescription:
Slim Digital Ballast is the most popular ballast in the market. It has small size and weight. The Low-wattage HID bulb is designed for automotive use for quick start and hot re-strike. HID ballast follows the six operation stages of bulb: turn-on, ignition, take-over, warm-up, run-up and steady state. So HID ballast needs not only different control modes for different stages but also complicated timing control.
The main system is with the following good quality modules.
1. Low-gain low bandwidth system.
2. Powerful DSP.
3. Ignition coil with Platinum
4. MOSFET
5. Capacitance
6. Microchip
Specification:
1) Measurement: 50*42*14 mm
2) Weight: 0.23 kg
3) Length of cable: 410 mm
4) Connector: AMP
5) Input voltage:9-16V
6) Working temperature: -40 ~ 105°C.
7) Output frequency:375±75HZ
8) Max input current:6A
9) Output power(stable state): 35/55W
10) Max. start voltage: 23000 V
11) Life time: ≥10000 hours
Performance:
1) Light output is stable within ±10.5% during the 125 to 145 second time interval.
2) At steady state, there's minimum variation in color, such as color bursts.
3) It's able to respond to momentary off times of varying periods of time after achieving steady state conditions and thermal stabilization of the bulb.
4) It meets performance specifications when supplied by primary positive input voltages varying from 9 to 18 VDC.
5) It provides over current protection.
6) The system is designed to be compatible with the electromagnetic environment generated by the motor vehicle and its equipment.
7) Immunity to radiated fields.
8) Immunity to conducted sinusoidal bursts.
9) Immunity to jump start voltages.
Strict test:
1) Two hours aging test
2) Connection circuit protection test
3) Over-voltage protection test
4) Flashing light concussion test
5) Quakeproof capability test
6) Cold boot/warm boot test
7) Polarity protection test
8) Short circuit protection test
9) EMC test
10) Ballast and bulb matching test
