high quality hydraulic hoses SAE 100 R9 R12 EN 856 4SH 4SP
Recommended for:High pressure hydraulic oil lines for applications with crude oils, fuel oils,lubricating oils and gasoline.
Tube:Black, oil resistant,oil resistant synthetic rubber
Reinforcement: four plies of spirally wrapped high tensile steel wire.
Cover:Black, oil and weather resistant synthetic rubber
Construction:
This hose shall consist of an inner tube of oil resistant
synthetic rubber,4 layers of spiral steel wire
wrapped in alternating directions,and an oil and
weather resistant synthetic rubber cover.
Application:
Hose range suitable for
use with petroleum base hydraulic fluids within
a temperature range of -40℃- +100℃.
| M-ES6 4P wire spiral hydraulic rubber hose | |||||||||||||||
| Type | SIZE | SIZE | ID | WD | OD | WP | BP | min BR | WT | ||||||
| mm | inch | Min | Max | Min | Max | Min | Max | Mpa | Psi | Mpa | Psi | Inch | mm | Kg/m | |
| ES4P-04 | 6.3 | 1/4 | 6.2 | 7.0 | 14.1 | 15.3 | 17.1 | 18.7 | 45 | 6625 | 180 | 26100 | 5.91 | 150 | 0.64 |
| ES4P-06 | 10 | 3/8 | 9.3 | 10.1 | 16.9 | 18.1 | 20.6 | 22.2 | 44.5 | 6450 | 178 | 25810 | 7.09 | 180 | 0.75 |
| ES4P-08 | 12.5 | 1/2 | 12.3 | 13.5 | 19.4 | 21.0 | 23.8 | 25.4 | 41.5 | 6020 | 166 | 24070 | 9.06 | 230 | 0.89 |
| ES4P-10 | 16 | 5/8 | 15.5 | 16.7 | 23.0 | 24.6 | 27.4 | 29.0 | 35 | 5075 | 140 | 20300 | 9.84 | 250 | 1.1 |
| ES4P-12 | 19 | 3/4 | 18.6 | 19.8 | 27.4 | 29.0 | 31.4 | 33.0 | 35 | 5075 | 148 | 21460 | 11.81 | 300 | 1.5 |
| ES4P-16 | 25 | 1 | 25.0 | 26.4 | 34.5 | 36.1 | 38.5 | 40.9 | 28 | 4060 | 112 | 16240 | 13.39 | 340 | 2.00 |
| ES4P-20 | 31.5 | 1 1/4 | 31.4 | 33.0 | 45.0 | 47.0 | 49.2 | 52.4 | 21 | 3045 | 84 | 12180 | 18.11 | 460 | 3.00 |
| ES4P-24 | 38 | 1 1/2 | 37.7 | 39.3 | 51.4 | 53.4 | 55.6 | 58.8 | 18.5 | 1680 | 74 | 10730 | 22.05 | 560 | 3.40 |
| ES4P-32 | 51 | 2 | 50.4 | 52.0 | 64.3 | 66.3 | 68.2 | 71.4 | 16.5 | 2390 | 66 | 9570 | 25.98 | 660 | 4.35 |
Packing:
Our Services
We can offer OEM Services
We can provide FREE SAMPPLE for our customers
We can crimp hose assembly for our customers.
We welcome clients to visit our factory leading to better understanding of our production .
FAQ
1.How to get free samples ?
A: Send your address ,your telphone number ,post code ,and express account number to our mail box .and told us which model of samples you need .
2.Who pay for the express cost ?
A: We can support you free samples each model 1-3 pcs ,and we do not pay for express cost .
3.How to pay ?
A:We support transfer money by all kinds of ways
