Green energy Good quality High COP water to water Solar Heat Pump (Open Loop) with 63.5kw with RA10a R 417a

Specifications

1.High capacity water to water solar heat pump
2. Intelligent controller
3.Strict noise control
4.Green energy

INTRODUCTION



 Deron water to water heat pump with high capacity type for open loop installion







 Water to water Heat Pump use the advanced tech components from all the world , self-patented design  with high-efficiency , absorbs energy from underground and then transfers it into water. It can also take the energy from the water and transfer it to the ground. So the warm water to under floor heating pipes or fan coils.





Feature:

1.Copeland with R417a or Daikin with R410a scroll compressor,high effeciency and stable fucntions.

2.Emerson ALCO thermal expansion valv, with accurate and stable throtting performance.

3.Adoped high effciency stainless steel heat exchanger for Evaporater and Condensor.

4.Coated steel or #304 stainless steel case, avoiding rust and durable.

5.Floating support for compressor to reduce virbration at the most extent and Sandwich noise insulation inside the cabinet and noise jacket for compressor to reduce noise mostly.

6.Strictly testing in the factory before shipping.





Product Detail:





Specification:

Model	DE-52W/S
Power Suply (V/ph/Hz)	380/3/50
*Heating Capacity(kw)	24
*Rated Power input(kw)	5.2
**Heating Capacity(kw)	22.5
**Rated Power input(kw)	4.5
Refrigerant	R417A
Refrigerant Weight(g)	2800
Max Current(A)	15
Rated water temp.(°C)	55
Max. water temp.(°C)	60
Level against electric shock	I
Water proof grade	IPX4
Net Weigt (kg)	140
Net Size (mm)(L×W×H)	600×620×830
Packing Size (mm)(L×W×H)	680×700×930
Required hot water flow rate (m³/h)	4.8
Required water source flow rate (m³/h)	5.2
Water Connection	G1"
Noise dB	≤42

Testing Condition:  *Heating: Water source temp.  (In/Out):15°C /7°C, Water temp. (Initial/Final):15°C/55°C.
                              **Heating: Water source temp.  (In/Out):10°C/7°C, Water temp. (In/Out):30°C/35°C





Certificate:









Installing direction & picture:















Factory Outlook:
