2 Ton Electric Forklift Truck Lifting Height 4m With Full Free Mast
US$ 11,800 - 11,900
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
VLIFT
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai qingdao ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2 Ton Electric Forklift Truck Lifting Height 5m With Full Free MastUS$ 12,500 - 12,600MOQ: 1 Unit -
2 Ton Electric Forklift Truck Lifting Height 6m With Full Free MastUS$ 12,900 - 13,000MOQ: 1 Unit
-
2 Ton Three Wheel Full Electric Forklift With Charger With Battery With Side ShiftUS$ 11,500 - 11,600MOQ: 1 Set
-
2.5 Ton Full Electric Battery Forklift Truck Lifting Height 6M With 3 Stage 6 m Full Free MastUS$ 12,800 - 13,000MOQ: 1 Set
-
2.5 Ton Electric Forklift With Explosion-proofUS$ 26,700 - 28,000MOQ: 1 Set
Condition
New
Place of Origin
Jiangsu, China
Brand Name
VLIFT
Model Number
CPCB20
Type
Other, electric forklift truck
Power Souce
AC Motor
Rated Loading Capacity
2000kg
Max. Lifting Height
4000mm
Min. Lifting Height
2145mm
Fork Length
1070mm
Fork Width
122mm
Overall Dimensions
2245*1150*2145mm(L*W*H)
Certification
ISO Certificate
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
2 ton electric forklift truck with low price
| CPCB20 TECHNOLOGY SPECIFICATION | |||
| Manufacturer | VLIFT | ||
| Model | CPCB20 | ||
| Load capacity | kg | 2000 | |
| Load center | mm | 500 | |
| Power unit | Battery | ||
| Operator type | Driver/seat | ||
| Tire type | pneumatic | ||
| Wheel(x=driving) | Front/rear | 2X/2 | |
| Max. lifting height | mm | 3000 | |
| Free lift | mm | 160 | |
| Fork size | L*W*T | mm | 1070*122*40 |
| Tilt range | Mast forward/backward | deg | 6/12 |
| Overall length(without fork) | mm | 2245 | |
| Total width | mm | 1150 | |
| Mast height (fork lowering) | mm | 1870 | |
| Overall height fork raised | With backrest | mm | 5030 |
| Height to head guard | mm | 2145 | |
| Turning raduis(outside) | mm | 1980 | |
| Front overhang ( face of fork to front axle) | mm | 445 | |
| Min. right angle stacking aisle | not add load length&clearence | mm | 2425 |
| Speed | Max Travelling full load | km/h | 13.5 |
| Max Travelling no load | km/h | 15 | |
| Lifting full load | mm/s | 240 | |
| Lifting no load | mm/s | 450 | |
| Gradeability | full load | % | 12.5 |
| Truck weight(with standard battery) | kg | 3440 | |
| Weight distribution | Full load front/rear | kg | 4565/875 |
| No load front/rear | kg | 1445/1995 | |
| Tires | Number | front/rear | 2/2 |
| Model | front axle | 21*8-9-16PR | |
| rear axle | 18*7-8-14PR | ||
| Wheelbase | mm | 1400 | |
| Tread | Front/rear | mm | 955/950 |
| Ground clearence | At lowest point(mast) | mm | 110 |
| Frame | mm | 115 | |
| Brake | Service brake | Hydraulic-foot pedal | |
| Parking brak | Mechanical-hand lever | ||
| Battery | Voltage/capacity | V/AH/5hr | 48V-450 |
| Weight with box (standard) | kg | 825 | |
| Electric motor | AC Driving motor | kw | 11 |
| DC Hydraulic driving motor | kw | 8.6 | |
| AC Hydraulic driving motor (as option) | kw | 13 | |
| Control type | Driving AC,lifting AC(as option ) | ||
| Operating pressure | kg/cm² | 175 | |
Certifications
Standard Configuration
wide vision mast,standard fork,standard seat,direction switch,backrest,reversing lights,reversing buzzer,back-up mirror,light switch,light armor rack,klaxon,two pieces of multi-way valve,electric control,rear combination lamp,overhead guard,rain cover,urable tyre,lasso-parking brake,lifting and tilt joystick,rate-limiting valve of lifting,draebar pin,lighting,adjustable steering wheel,lilt line self-lock valve,full hydraulic power steering,handle,tool box,combination instrument,hydraulic return filter,hydraulic oil suction filter,hydraulic vernier,switch,brake,turning indicator
options
windscreen,two/three full-free mast,luxury seat,solid tyre,warning light,fan,colored tyre(white/green),customer appointed color
attachment
side shift,fork positioner,tippong fork,string lever,hook,ectended fork,fork sleeve,crane boom,roll clamp
