Types of Fan Blades
US$ 100 - 300
MOQ: 10 Sets
Key Specifications
Get Latest Price
Electric Current Type:
AC
Mounting:
Wall Fan
Blade Material:
Stainless Steel
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Electric Current Type
AC
Mounting
Wall Fan
Blade Material
Stainless Steel
Place of Origin
Shandong, China
Brand Name
FT
Model Number
ft-1000
Voltage
380
Power
750
Air Volume
32500
Speed
600
Certification
CCC, CE, GS
After-sales Service Provided
Engineers available to service machinery overseas
Products Features:
1) reasonable cone designing with big air volume, low noise
2) imported bearing, high strength, low noise and long service life
3) shutter are made of high strength hot-galvanized steel sheet, anti-oxidant, light weight and no distortions
4) high strength dabber aluminum-magnesium alloy wheel. High strength and long service life
5) Mirror designed and injection molding Stainless steel blade, with big air volume, never distortion and broken
6)high efficient and energy-saving motor with CCC certificate, protection class: IP55, insulation class: F grade
1) reasonable cone designing with big air volume, low noise
2) imported bearing, high strength, low noise and long service life
3) shutter are made of high strength hot-galvanized steel sheet, anti-oxidant, light weight and no distortions
4) high strength dabber aluminum-magnesium alloy wheel. High strength and long service life
5) Mirror designed and injection molding Stainless steel blade, with big air volume, never distortion and broken
6)high efficient and energy-saving motor with CCC certificate, protection class: IP55, insulation class: F grade
| Model specifications | Diameter Blades- mm | Blades rotational speed- rpm | Motor rotational speed- rpm | Air flow m3/h | Total pressure Pa | Noise decibels | Import power-W | Rated voltage-V | High mm | Width mm | Thick mm |
| JLF-900 (35' ' ) | 750 | 630 | 1400 | 22000 | 65 | ≤ 65 | 370 | 380 | 900 | 900 | 1050 |
| JLF-1100 (43' ' ) | 1000 | 600 | 1400 | 32500 | 70 | ≤ 70 | 750 | 380 | 1100 | 1100 | 1050 |
| JLF-1220 (48' ' ) | 1100 | 460 | 1400 | 38000 | 73 | ≤ 70 | 750 | 380 | 1220 | 1220 | 1050 |
| JLF-1380 (54' ' ) | 1250 | 439 | 1400 | 44000 | 80 | ≤ 70 | 1100 | 380 | 1380 | 1380 | 1050 |
