Specifications
Long arm computerized single needle quilting machineMain motor:stepper motor
Stitch length:2-7mm
Rotary hook:big rotary hook
HAIMEN HAOXIN MACHINERY CO., LTD
HXD-C COMPUTERIZED SINGLE NEEDLE QUILTING MACHINE
| Model | Working width(m) | Machine size(m) | Max size of quilt(m) | Max design size | Speed(rpm) | Weight(T) | Power |
| HXD-26C | 2.6 | 3.55*5*1.67 | 2.6*2.8 | 2.4*2.6 | 2200 | 0.8 | 1.5 |
| HXD-28C | 2.8 | 3.8*5.4*1.67 | 2.8*3.2 | 2.6*3.0 | 2200 | 0.85 | 1.5 |
| HXD-30C | 3 | 4.05*5.4*1.67 | 3.0*3.2 | 2.8*3.2 | 2200 | 0.9 | 1.5 |
| HXD-34C | 3.4 | 4.45*5.8*1.67 | 3.4*3.6 | 3.2*3.6 | 2200 | 1 | 1.5 |
Performance:
1.Needle head is controlled by one big frame.
2.Easy modification operation of needle distance and speed.
3. clockwise-counterclockwise quilting and empty forward or backward or thread-through button is provided.
4. the needle automatically stops at high position when the machine stops.
5. the machine stops when any broken thread is automatically detected.
6. Quilting condition and operation indication are shown in real time.
7. It automatically returns to original point.
8. It has the function of pattern tracing to make the needle position quickly.
9.It has the function of pattern browsing.
10.It has the function of work-piece and time statistics.
11.Through pattern side setting up ,it can automatically enlarge or reduce patterns.
The head of HXD-C:
Quilts produced by the machine:
Safe packing:
Welcome to our factory!
